– 47 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
JR19 1-216-296-00 SHORT 0
JR22 1-216-295-00 SHORT 0
JR24 1-216-295-00 SHORT 0
JR27 1-216-295-00 SHORT 0
JR28 1-216-864-11 METAL CHIP 0 5% 1/16W
JR29 1-216-295-00 SHORT 0 (CDX-2250)
JR30 1-216-295-00 SHORT 0 (CDX-2250)
JR31 1-216-296-00 SHORT 0
JR33 1-216-295-00 SHORT 0
JR34 1-216-295-00 SHORT 0
JR35 1-216-296-00 SHORT 0
JR36 1-216-296-00 SHORT 0
JR37 1-216-296-00 SHORT 0
JR39 1-216-295-00 SHORT 0
JR45 1-216-296-00 SHORT 0
JR45 1-216-296-00 SHORT 0
JR46 1-216-296-00 SHORT 0
JR46 1-216-296-00 SHORT 0
JR47 1-216-296-00 SHORT 0 (CDX-2250)
JR48 1-216-295-00 SHORT 0 (CDX-2250)
JR60 1-216-295-00 SHORT 0
JR86 1-216-295-00 SHORT 0 (CDX-2250)
JR90 1-216-295-00 SHORT 0
< COIL >
L601 1-414-137-31 INDUCTOR 0.22uH
L602 1-410-521-11 INDUCTOR 100uH
L801 1-410-513-11 INDUCTOR 22uH
L901 1-416-539-11 INDUCTOR 370uH
< JACK >
PJ401 1-785-628-11 JACK, PIN 4P LINE OUT
< TRANSISTOR >
Q101 8-729-920-21 TRANSISTOR DTC314TKH04
Q102 8-729-920-21 TRANSISTOR DTC314TKH04
Q201 8-729-920-21 TRANSISTOR DTC314TKH04
Q202 8-729-920-21 TRANSISTOR DTC314TKH04
Q401 8-729-027-52 TRANSISTOR DTC124EKA-T146
Q402 8-729-901-05 TRANSISTOR DTA124EK
Q601 8-729-030-51 TRANSISTOR 2SA1515S-R-TP
Q602 8-729-030-51 TRANSISTOR 2SA1515S-R-TP
Q605 8-729-620-06 TRANSISTOR 2SC3052-EF
Q606 8-729-620-06 TRANSISTOR 2SC3052-EF
Q801 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q901 8-729-019-00 TRANSISTOR 2SD2394-G
Q902 8-729-901-05 TRANSISTOR DTA124EK
Q904 8-729-015-11 TRANSISTOR 2SD1802FAST-TL
Q905 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q906 8-729-901-05 TRANSISTOR DTA124EK
Q907 8-729-019-00 TRANSISTOR 2SD2394-G
Q908 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q909 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q910 8-729-920-85 TRANSISTOR 2SD1664-QR
Q911 8-729-620-06 TRANSISTOR 2SC3052-EF
Q912 8-729-620-06 TRANSISTOR 2SC3052-EF
Q913 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q915 8-729-822-84 TRANSISTOR 2SB1202FAST
Q916 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q917 8-729-101-07 TRANSISTOR 2SB798-DL
Q918 8-729-027-43 TRANSISTOR DTC114EKA-T146
< RESISTOR >
R101 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R102 1-216-073-00 METAL CHIP 10K 5% 1/10W
R103 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R104 1-216-214-00 RES,CHIP 4.7K 5% 1/8W
R105 1-216-049-11 RES,CHIP 1K 5% 1/10W
R106 1-216-049-11 RES,CHIP 1K 5% 1/10W
R107 1-216-075-00 METAL CHIP 12K 5% 1/10W
R108 1-216-075-00 METAL CHIP 12K 5% 1/10W
R109 1-216-129-00 METAL CHIP 2.2M 5% 1/10W
R110 1-216-129-00 METAL CHIP 2.2M 5% 1/10W
R111 1-216-083-00 METAL CHIP 27K 5% 1/10W
R112 1-216-083-00 METAL CHIP 27K 5% 1/10W
R113 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R201 1-216-071-00 METAL CHIP 8.2K 5% 1/10W
R202 1-216-073-00 METAL CHIP 10K 5% 1/10W
R203 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R204 1-216-065-00 RES,CHIP 4.7K 5% 1/10W
R205 1-216-049-11 RES,CHIP 1K 5% 1/10W
R206 1-216-049-11 RES,CHIP 1K 5% 1/10W
R207 1-216-075-00 METAL CHIP 12K 5% 1/10W
R208 1-216-075-00 METAL CHIP 12K 5% 1/10W
R209 1-216-129-00 METAL CHIP 2.2M 5% 1/10W
R210 1-216-129-00 METAL CHIP 2.2M 5% 1/10W
R211 1-216-083-00 METAL CHIP 27K 5% 1/10W
R212 1-216-083-00 METAL CHIP 27K 5% 1/10W
R213 1-216-059-00 METAL CHIP 2.7K 5% 1/10W
R401 1-216-113-00 METAL CHIP 470K 5% 1/10W
R402 1-216-049-11 RES,CHIP 1K 5% 1/10W
R601 1-216-221-00 RES,CHIP 9.1K 5% 1/8W
(CDX-3500)
R601 1-216-230-00 RES,CHIP 22K 5% 1/8W
(CDX-2250)
R602 1-249-417-11 CARBON 1K 5% 1/4W F
R603 1-249-417-11 CARBON 1K 5% 1/4W F
R604 1-216-077-00 METAL CHIP 15K 5% 1/10W
(CDX-2250)
R605 1-216-077-00 METAL CHIP 15K 5% 1/10W
(CDX-2250)
R607 1-216-025-00 RES,CHIP 100 5% 1/10W
R608 1-216-081-00 METAL CHIP 22K 5% 1/10W
R611 1-216-049-11 RES,CHIP 1K 5% 1/10W
R612 1-216-049-11 RES,CHIP 1K 5% 1/10W
R613 1-216-049-11 RES,CHIP 1K 5% 1/10W
R614 1-216-049-11 RES,CHIP 1K 5% 1/10W
R615 1-249-429-11 CARBON 10K 5% 1/4W
R616 1-249-417-11 CARBON 1K 5% 1/4W F
R617 1-216-049-11 RES,CHIP 1K 5% 1/10W
R618 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R620 1-247-807-31 CARBON 100 5% 1/4W
R622 1-216-081-00 METAL CHIP 22K 5% 1/10W
R701 1-216-025-00 RES,CHIP 100 5% 1/10W
R702 1-216-025-00 RES,CHIP 100 5% 1/10W
