Sony CDX-CA700 - Disc in Board; Servo Board

10
CDX-CA700/CA700X
1 CN3
2 Removal the solders.
3 P 2x3
6 PS 2x4
5 PS 2x4
4 loading motor assy
7 SERVO board
8 connector
optical pick-up block
2-6. DISC IN BOARD
2-7. SERVO BOARD
3 claws
2 DISC IN board
4 guide (disc)
1 PS 2x3
