Sony CDX-CA700 - Shaft Roller Assy; Floating Block Assy

11
CDX-CA700/CA700X
1 tension spring (KF1)
2 tension spring (KR1)
8 compression spring (FL)
7 floating block assy
9 compression spring (FL)
5 Fit lever (D) in the
direction of the arrow.
3 damper (T)
4 damper (T)
6 Turn loading ring in the
direction of the arrow.
Fig. 1
1 tension spring (RA3)
2 arm (roller T)
3 retaing ring (roller)
4 bearing (roller)
5 shaft roller assy
retaing ring (roller)
arm
arm
washer (RA)
washer (RA)
bearing (roller)
bearing (roller)
2-9. FLOATING BLOCK ASSY
2-8. SHAFT ROLLER ASSY
• When installing, take note of the positions
arm (roller) and washers. (Fig. 1)
