Sony CDX-CA700 - Heat Sink; Chassis (T.U) Assy; Qq

9
CDX-CA700/CA700X
4 chassis (T.U) sub ass
y
3 P 2x3
2 P 2x3
1 Unsolder the
lead wires.
black
red
white
2-5. CHASSIS (T.U) ASSY
2-4. HEAT SINK
1 PTT 2.6x10
3 PTT 2.6x1
0
4 heat sink
2 PTT 2.6x16
