39
CDX-CA700/CA700X
SECTION 5
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Abbreviation
CND: Canadian model
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.
DISC IN KEY
1-659-836-11 DISC IN BOARD
*************
< SWITCH >
SW1 1-529-566-31 SWITCH, PUSH (1 KEY) (DISC IN)
SW2 1-529-566-31 SWITCH, PUSH (1 KEY) (SELF)
*************************************************************
KEY BOARD
**********
1-694-882-11 CONDUCTIVE BOARD, CONNECTION
3-236-278-01 PLATE (LCD), LIGHT GUIDE
3-236-279-01 HOLDER
3-236-284-01 PLATE (LCD), GROUND
3-236-438-01 ILLUMINATOR (LCD)
< CAPACITOR >
C952 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C953 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C956 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C958 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C959 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C961 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C962 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C971 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN901 1-794-065-22 PLUG, CONNECTOR 14P
< DIODE >
D901 8-719-081-97 DIODE MMDL914T1 (US,CND)
D901 8-719-404-50 DIODE MA111-TX (AEP,UK)
D903 6-500-031-01 DIODE MM3Z18VST1 (US,CND)
D903 8-719-056-93 DIODE UDZ-TE-17-18B (AEP,UK)
D908 6-500-023-01 DIODE MM3Z5V6ST1 (US,CND)
D908 8-719-158-15 DIODE RD5.6S-B (AEP,UK)
D911 8-719-069-56 DIODE UDZS-TE-17-6.2B (US,CND)
D911 8-719-422-64 DIODE MA8062-M (AEP,UK)
D912 8-719-069-56 DIODE UDZS-TE-17-6.2B (US,CND)
D912 8-719-422-64 DIODE MA8062-M (AEP,UK)
D913 8-719-069-56 DIODE UDZS-TE-17-6.2B (US,CND)
D913 8-719-422-64 DIODE MA8062-M (AEP,UK)
D971 8-719-069-56 DIODE UDZS-TE-17-6.2B (US,CND)
D971 8-719-422-64 DIODE MA8062-M (AEP,UK)
D972 6-500-022-01 DIODE MM3Z5V1ST1 (US,CND)
D972 8-719-976-99 DIODE DTZ5.1B (AEP,UK)
< IC >
IC901 6-701-640-01 IC LC75813T-E
IC971 6-600-047-01 IC RS-670
< LIQUID CRYSTAL DISPLAY >
LCD901 1-804-619-11 DISPLAY PANEL, LIQUID CRYSTAL
< DIODE >
LED901 8-719-061-16 LED CL-190SR-CD-T (OFF) (CA700X)
LED901 8-719-078-15 LED CL-165Y/PG-D-T (OFF) (CA700)
LED903 8-719-080-04 LED CL-190UB-X-T (MBP)
LED912 8-719-061-16 LED CL-190SR-CD-T (ENTER) (CA700X)
LED912 8-719-078-15 LED CL-165Y/PG-D-T (ENTER) (CA700)
LED914 8-719-080-04 LED CL-190UB-X-T (EQ7)
LED917 8-719-061-16 LED CL-190SR-CD-T (LIST) (CA700X)
LED917 8-719-078-15 LED CL-165Y/PG-D-T (LIST) (CA700)
LED931 8-719-076-58 LED NSSW440-BRS (LCD BACK LIGHT)
LED941 8-719-076-58 LED NSSW440-BRS (LCD BACK LIGHT)
< SWITCH >
LSW902 1-762-620-11 SWITCH, KEYBOARD (WITH LED) (SOURCE)
(CA700)
LSW902 1-771-476-11 SWITCH, KEYBOARD (WITH LED) (SOURCE)
(CA700X)
LSW904 1-762-620-11 SWITCH, KEYBOARD (WITH LED) (MODE)
(CA700)
LSW904 1-771-476-11 SWITCH, KEYBOARD (WITH LED) (MODE)
(CA700X)
LSW905 1-762-620-11 SWITCH, KEYBOARD (WITH LED) (DSPL/PTY)
(CA700)
LSW905 1-771-476-11 SWITCH, KEYBOARD (WITH LED) (DSPL/PTY)
(CA700X)
LSW906 1-771-610-11 SWITCH, TACTILE (WITH LED) (AF) (CA700)
LSW906 1-771-883-11 SWITCH, TACTILE (WITH LED) (AF) (CA700X)
LSW907 1-762-620-11 SWITCH, KEYBOARD (WITH LED) (SCRL)
(CA700)
LSW907 1-771-476-11 SWITCH, KEYBOARD (WITH LED) (SCRL)
(CA700X)
LSW910 1-771-610-11 SWITCH, TACTILE (WITH LED) (TA) (CA700)
LSW910 1-771-883-11 SWITCH, TACTILE (WITH LED) (TA)
(CA700X:AEP,UK)
LSW911 1-762-620-11 SWITCH, KEYBOARD (WITH LED) (SOUND)
(CA700)
