Sony CDX-CA700 - Optical Pick-up Block Removal; Optical Pick-up Block Removal Procedure

12
CDX-CA700/CA700X
1 P 2x3
4 P 2x3
5 spring (feed), plate
6 shaft (feed) assy
2 sled motor assy
3 optical pick-up block
2-10. OPTICAL PICK-UP BLOCK
