14
CDX-CA700/CA700X
Pin No. Pin Name I/O Pin Description
49 TUNON O Tuner power supply control signal output to power supply (IC601)
50 PW ON O System power supply control signal output to power supply (IC601)
51 TSTB O CD text parameter strob signal output to servo IC (IC1)
52 RFOK I RF OK signal input from servo IC (IC1)
53 CD RST O Reset signal output to servo IC (IC1)
54 A0 O
Command/parameter identification signal output to servo IC (IC1)
“L”: Command, “H”: Parameter
55 STB O Data strob signal output to servo IC (IC1)
56 X EN O Crystal oscillation control signal output Not used in this set.
57 LIMIT I CD Mechanism in-limit switch signal input from limit switch (SW3)
58 PH1 I CD Mechanism PH1 detection signal input Not used in this set.
59 D SW I CD Mechanism down switch signal input from down switch (SW5)
60 INSW/PH2 I CD Mechanism disc-in switch detection signal input from disc-in switch (SW1)
61 NC (PH3) I CD Mechanism PH3 detection signal input Not used in this set.
62 CD LM LO O CD Mechanism loading motor control signal output to loading motor drive (IC2)
63 CD LM EJ O CD Mechanism eject motor control signal output to loading motor drive (IC2)
64 4VPRE/NCO I/O Hi-Volt power selection “L”: with, “H”: without (US, Canadian)/open (AEP, UK)
65 PREOUTMENU/NCO I/O
Pre-out (4 V/5.5 V) menu selection “L”: with, “H”: without set up signal input
(US, Canadian)/open (AEP, UK)
66 AMPATT O Power amp ATT control signal output to power amp (IC751)
67 AMPON O Power amp standby control signal output to power amp (IC751)
68 CDMD ON O CD mechanism deck power supply control signal output
69 ATT O System ATT control signal output
70 VOLATT O Electrical volume ATT control signal output to electrical volume (IC331)
71 – 73 NCO O Not used. (Open)
74 MP3SEL I
MP3 control select signal input “L”: MP3 CD changer control correspondence,
“H”: not correspondence
75 SUB SEL I Sub-out function detection signal input “H”: without, “L”: with
76 SW SHIFT O Not used in this set. (Open)
77 COLSEL I Key illumination color selection detection signal input “L”: amber, “H”: green
78 NCO O Not used. (Open)
79 XCD ON O CD on signal output “H”: Play, “L”: Loading or standby
80 – 85 NCO O Not used. (Open)
86 E2P SIO I/O EEPROM serial data signal input/output
87 E2P CKO O EEPROM serial clock signal output
88 NCO O Not used. (Open)
89 FLASH W I Flash microcomputer write detection signal input “L”: Write mode
90 NIL/NS MASK O Connect to ground (US, Canadian)/Noise mask signal output (AEP, UK)
91 AD ON O Key power supply control signal output “L”: key active
92 DOORIND O Sub panel power supply control signal output
93 ILLON O Illumination power supply control signal output
94 DOOR SW I Front panel open/close detection signal input “L”: Close, “H”: Open
95 DAVSS Ground pin
96 RE IN1 I Rotary encoder signal input from rotary encoder (RE901)
97 RE IN0 I Rotary encoder signal input from rotary encoder (RE901)
98 RC IN1 I
Rotary commander shift key signal input from remote in jack (J561)
“L”: Shift key on
99 NCO O Not used. (Connect to ground.)
100 DAVDD Power supply pin (+5 V)
