43
CDX-CA700/CA700X
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
MAIN
D585 8-719-056-82 DIODE UDZ-TE-17-6.2B (AEP,UK)
D611 8-719-053-18 DIODE 1SR154-400TE-25
D612 8-719-053-18 DIODE 1SR154-400TE-25
D613 8-719-053-18 DIODE 1SR154-400TE-25
D614 8-719-053-18 DIODE 1SR154-400TE-25
D621 8-719-988-61 DIODE 1SS355TE-17
D625 8-719-987-69 DIODE DAN217
D701 8-719-988-61 DIODE 1SS355TE-17
D702 8-719-988-61 DIODE 1SS355TE-17
D703 6-500-031-01 DIODE MM3Z18VST1 (US,CND)
D703 8-719-056-93 DIODE UDZ-TE-17-18B (AEP,UK)
D710 8-719-085-72 DIODE UMZ6.8ENTR
D711 8-719-085-72 DIODE UMZ6.8ENTR
D712 8-719-085-72 DIODE UMZ6.8ENTR
D721 8-719-079-55 DIODE PTZ-TE25-22
D722 8-719-079-55 DIODE PTZ-TE25-22
D723 8-719-079-55 DIODE PTZ-TE25-22
D724 8-719-079-55 DIODE PTZ-TE25-22
D731 8-719-079-55 DIODE PTZ-TE25-22
D732 8-719-079-55 DIODE PTZ-TE25-22
D733 8-719-079-55 DIODE PTZ-TE25-22
D734 8-719-079-55 DIODE PTZ-TE25-22
D781 8-719-049-38 DIODE 1N5404TU
D782 6-500-025-01 DIODE MM3Z6V8ST1 (US,CND)
D782 8-719-056-83 DIODE UDZ-TE-17-6.8B (AEP,UK)
< IC >
IC20 8-759-331-71 IC NJM4558E(TE2) (AEP,UK)
IC51 8-759-492-59 IC SAA6588T-118 (AEP,UK)
IC331 6-701-403-01 IC TDA7406
IC332 8-759-711-85 IC NJM4580E-D
IC333 8-759-711-85 IC NJM4580E-D
IC501 6-801-199-03 IC MN101C49KCX2 (AEP,UK)
IC501 6-801-200-03 IC MN101C49KCY2 (US,CND)
IC551 6-701-405-01 IC PST3443UL
IC581 8-759-449-89 IC BA8270F-E2
IC601 6-600-051-01 IC AN80T51
IC751 8-759-827-14 IC TA8268AH
< JACK >
J10 1-815-185-12 JACK (ANTENNA)
J561 1-566-822-41 JACK (REMOTE IN)
< COIL >
L781 1-419-476-11 COIL, CHOKE 250uH
< JACK >
PJ151 1-774-700-11 JACK, PIN 6P (AUDIO OUT FRONT/REAR,
BUS AUDIO IN)
< TRANSISTOR >
Q21 8-729-120-28 TRANSISTOR 2SC1623-L5L6 (AEP,UK)
Q22 8-729-900-53 TRANSISTOR DTC114EK (AEP,UK)
Q171 8-729-023-22 TRANSISTOR 2SD2114K
Q175 8-729-027-60 TRANSISTOR DTC144TKA-T146 (AEP,UK)
Q181 8-729-023-22 TRANSISTOR 2SD2114K
Q185 8-729-027-60 TRANSISTOR DTC144TKA-T146 (AEP,UK)
Q271 8-729-023-22 TRANSISTOR 2SD2114K
Q275 8-729-027-60 TRANSISTOR DTC144TKA-T146 (AEP,UK)
Q281 8-729-023-22 TRANSISTOR 2SD2114K
Q285 8-729-027-60 TRANSISTOR DTC144TKA-T146 (AEP,UK)
Q350 8-729-920-85 TRANSISTOR 2SD1664-QR
Q351 8-729-021-82 TRANSISTOR 2SD2396K
Q352 8-729-047-76 TRANSISTOR FMC2A-T148
Q353 8-729-900-53 TRANSISTOR DTC114EK
Q551 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q571 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q581 8-729-900-53 TRANSISTOR DTC114EK
Q585 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q601 8-729-106-60 TRANSISTOR 2SB1115A
Q603 8-729-047-76 TRANSISTOR FMC2A-T148
Q621 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q622 8-729-900-53 TRANSISTOR DTC114EK
Q625 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q631 8-729-047-76 TRANSISTOR FMC2A-T148
< RESISTOR >
R10 1-216-864-11 METAL CHIP 0 5% 1/16W
R12 1-216-797-11 METAL CHIP 10 5% 1/16W
R13 1-216-815-11 METAL CHIP 330 5% 1/16W
R14 1-216-815-11 METAL CHIP 330 5% 1/16W
R18 1-216-797-11 METAL CHIP 10 5% 1/16W
(AEP,UK)
R19 1-216-797-11 METAL CHIP 10 5% 1/16W
(AEP,UK)
R21 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
(AEP,UK)
R22 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
(AEP,UK)
R23 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
(AEP,UK)
R24 1-216-833-11 METAL CHIP 10K 5% 1/16W
(AEP,UK)
R25 1-216-833-11 METAL CHIP 10K 5% 1/16W
(AEP,UK)
R26 1-216-809-11 METAL CHIP 100 5% 1/16W
(AEP,UK)
R27 1-216-845-11 METAL CHIP 100K 5% 1/16W
(AEP,UK)
R28 1-216-857-11 METAL CHIP 1M 5% 1/16W
(AEP,UK)
R28 1-216-864-11 METAL CHIP 0 5% 1/16W
(US,CND)
R29 1-216-809-11 METAL CHIP 100 5% 1/16W
(AEP,UK)
R29 1-216-864-11 METAL CHIP 0 5% 1/16W
(US,CND)
Ver 1.1
