CDX-F5510/F5510X/F5550EE
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R985 1-216-809-11 METAL CHIP 100 5% 1/10W
(F5510)
R985 1-216-813-11 METAL CHIP 220 5% 1/10W
(EXCEPT F5510)
R986 1-216-809-11 METAL CHIP 100 5% 1/10W
(F5510)
R986 1-216-813-11 METAL CHIP 220 5% 1/10W
(EXCEPT F5510)
R987 1-216-809-11 METAL CHIP 100 5% 1/10W
(F5510)
R987 1-216-813-11 METAL CHIP 220 5% 1/10W
(EXCEPT F5510)
R988 1-216-809-11 METAL CHIP 100 5% 1/10W
(F5510)
R988 1-216-813-11 METAL CHIP 220 5% 1/10W
(EXCEPT F5510)
R989 1-216-809-11 METAL CHIP 100 5% 1/10W
(F5510)
R989 1-216-813-11 METAL CHIP 220 5% 1/10W
(EXCEPT F5510)
R990 1-216-809-11 METAL CHIP 100 5% 1/10W
(F5510)
R990 1-216-813-11 METAL CHIP 220 5% 1/10W
(EXCEPT F5510)
R991 1-216-813-11 METAL CHIP 220 5% 1/10W
(F5510)
R991 1-216-814-11 METAL CHIP 270 5% 1/10W
(EXCEPT F5510)
R992 1-216-813-11 METAL CHIP 220 5% 1/10W
(F5510)
R992 1-216-814-11 METAL CHIP 270 5% 1/10W
(EXCEPT F5510)
< ROTARY ENCODER >
RE901 1-478-474-11 ENCODER, ROTARY
(PUSH DIAL SELECT/VOLUME)
< SWITCH >
S901 1-786-763-11 SWITCH, TACTILE (OFF)
S902 1-786-763-11 SWITCH, TACTILE (GP/PRESET +)
S903 1-786-763-11 SWITCH, TACTILE (LIST)
S904 1-786-763-11 SWITCH, TACTILE (DSO)
S905 1-786-763-11 SWITCH, TACTILE (EQ3)
S906 1-786-763-11 SWITCH, TACTILE (. SEEK – m)
S907 1-786-763-11 SWITCH, TACTILE (DSPL)
S908 1-786-763-11 SWITCH, TACTILE (GP/PRESET –)
S909 1-786-763-11 SWITCH, TACTILE (> SEEK + M)
S910 1-786-763-11 SWITCH, TACTILE (6)
S911 1-786-763-11 SWITCH, TACTILE (5/BBE MP)
S912 1-786-763-11 SWITCH, TACTILE (4/SHUF)
S913 1-786-763-11 SWITCH, TACTILE (3/REP)
S914 1-786-763-11 SWITCH, TACTILE (2)
S915 1-786-763-11 SWITCH, TACTILE (1)
S916 1-786-763-11 SWITCH, TACTILE (BTM)
S917 1-786-763-11 SWITCH, TACTILE (SENS)
S918 1-786-763-11 SWITCH, TACTILE (MODE)
S919 1-786-763-11 SWITCH, TACTILE (SOURCE)
*************************************************************
A-1087-889-A MAIN BOARD, COMPLETE
(including SPEAKER BOARD) (F5510)
A-1087-902-A MAIN BOARD, COMPLETE
(including SPEAKER BOARD) (F5550EE)
A-1087-912-A MAIN BOARD, COMPLETE
(including SPEAKER BOARD) (F5510X)
*********************
7-621-284-40 SCREW +P 2.6X10
7-685-134-19 SCREW +P 2.6X8 TYPE2 NON-SLIT
7-685-793-09 SCREW +PTT 2.6X8 (S)
7-685-795-09 SCREW +PTT 2.6X12 (S)
< CAPACITOR >
C101 1-126-964-11 ELECT 10uF 20% 50V
C106 1-126-965-11 ELECT 22uF 20% 50V
C107 1-126-964-11 ELECT 10uF 20% 50V
C109 1-104-665-11 ELECT 100uF 20% 25V
C111 1-126-964-11 ELECT 10uF 20% 50V
C113 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C403 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C404 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C406 1-136-153-00 FILM 0.012uF 5% 50V
C407 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C408 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C409 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C410 1-126-960-11 ELECT 1uF 20% 50V
C411 1-126-960-11 ELECT 1uF 20% 50V
C412 1-126-960-11 ELECT 1uF 20% 50V
C413 1-126-960-11 ELECT 1uF 20% 50V
C414 1-126-964-11 ELECT 10uF 20% 50V
C415 1-136-153-00 FILM 0.012uF 5% 50V
C416 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C417 1-126-947-11 ELECT 47uF 20% 35V
C418 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C420 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C421 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C422 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C423 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C424 1-126-964-11 ELECT 10uF 20% 50V
C425 1-126-964-11 ELECT 10uF 20% 50V
C426 1-126-964-11 ELECT 10uF 20% 50V
C428 1-126-964-11 ELECT 10uF 20% 50V
C430 1-126-947-11 ELECT 47uF 20% 35V
C433 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C434 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C435 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C436 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C437 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C438 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C439 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C440 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C441 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C443 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C444 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C446 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C447 1-126-961-11 ELECT 2.2uF 20% 50V
C450 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C451 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
