CDX-F5510/F5510X/F5550EE
SECTION 3
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA..: µPA..
uPB.. : µPB.. uPC..: µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
A-1172-509-A MAIN BOARD, COMPLETE
*********************
7-685-134-19 SCREW +P 2.6X8 TYPE2 NON-SLIT
7-685-794-09 SCREW +PTT 2.6X10 (S)
< CAPACITOR >
C101 1-126-964-11 ELECT 10uF 20% 50V
C106 1-126-965-11 ELECT 22uF 20% 50V
C107 1-126-964-11 ELECT 10uF 20% 50V
C109 1-104-665-11 ELECT 100uF 20% 25V
C111 1-126-964-11 ELECT 10uF 20% 50V
C113 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C403 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C404 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C406 1-136-154-00 FILM 0.012uF 5% 50V
C407 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C408 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C409 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C410 1-126-960-11 ELECT 1uF 20% 50V
C411 1-126-960-11 ELECT 1uF 20% 50V
C412 1-126-960-11 ELECT 1uF 20% 50V
C413 1-126-960-11 ELECT 1uF 20% 50V
C414 1-126-964-11 ELECT 10uF 20% 50V
C415 1-136-154-00 FILM 0.012uF 5% 50V
C416 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C417 1-126-947-11 ELECT 47uF 20% 35V
C418 1-162-965-11 CERAMIC CHIP 0.0015uF 10% 50V
C420 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C421 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C422 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C423 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C424 1-126-964-11 ELECT 10uF 20% 50V
C425 1-126-964-11 ELECT 10uF 20% 50V
C426 1-126-964-11 ELECT 10uF 20% 50V
C428 1-126-964-11 ELECT 10uF 20% 50V
C430 1-126-947-11 ELECT 47uF 20% 35V
C433 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C434 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C435 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C436 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C437 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C438 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C439 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C440 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C441 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C443 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C444 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C446 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C447 1-126-961-11 ELECT 2.2uF 20% 50V
C450 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C451 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C452 1-126-964-11 ELECT 10uF 20% 50V
C453 1-126-964-11 ELECT 10uF 20% 50V
C454 1-126-960-11 ELECT 1uF 20% 50V
C604 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C612 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C613 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C614 1-115-156-11 CERAMIC CHIP 1uF 10V
C615 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C616 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C618 1-126-947-11 ELECT 47uF 20% 35V
C619 1-126-964-11 ELECT 10uF 20% 50V
C620 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C701 1-104-665-11 ELECT 100uF 20% 25V
C704 1-104-665-11 ELECT 100uF 20% 25V
C706 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C707 1-104-665-11 ELECT 100uF 20% 25V
C709 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C801 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C802 1-126-947-11 ELECT 47uF 20% 35V
C807 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C809 1-104-665-11 ELECT 100uF 20% 25V
C810 1-126-916-11 ELECT 1000uF 20% 6.3V
C812 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C813 1-104-665-11 ELECT 100uF 20% 25V
C814 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C815 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C816 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C817 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C818 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C821 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C822 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C825 1-104-665-11 ELECT 100uF 20% 25V
C906 1-126-963-11 ELECT 4.7uF 20% 50V
C908 1-126-960-11 ELECT 1uF 20% 50V
C909 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C920 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C921 1-126-940-11 ELECT 330uF 20% 25V
C922 1-131-868-81 ELECT 3300uF 20% 16V
