Sony CDX-F5510 Service Manual

19
CDX-F5510/F5510X/F5550EE
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C990 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C991 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C992 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C993 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
C994 1-115-340-11 CERAMIC CHIP 0.22uF 10% 25V
< CONNECTOR >
CN751 1-817-536-11 CONNECTOR, BOARD TO BOARD 28P
CNJ900 1-580-907-41 PLUG, CONNECTOR (BUS CONTROL IN)
CNP802 1-569-907-11 SOCKET, CONNECTOR 12P
CNP901 1-774-701-21 PIN, CONNECTOR 16P
< JACK >
CNP900 1-566-822-41 JACK (REMOTE IN)
< DIODE >
D400 8-719-081-97 DIODE MMDL914T1
D600 8-719-036-94 DIODE RD5.6SB-T1
D701 8-719-081-97 DIODE MMDL914T1
D702 8-719-081-97 DIODE MMDL914T1
D801 8-719-081-97 DIODE MMDL914T1
D803 8-719-056-83 DIODE UDZ-TE-17-6.8B
D804 8-719-058-24 DIODE RB501V-40TE-17
D805 8-719-058-24 DIODE RB501V-40TE-17
D806 8-719-058-24 DIODE RB501V-40TE-17
D808 8-719-056-83 DIODE UDZ-TE-17-6.8B
D810 8-719-081-97 DIODE MMDL914T1
D811 8-719-109-97 DIODE RD6.8ESB2
D812 8-719-109-97 DIODE RD6.8ESB2
D813 8-719-109-97 DIODE RD6.8ESB2
D814 8-719-109-97 DIODE RD6.8ESB2
D815 8-719-109-97 DIODE RD6.8ESB2
D816 8-719-109-97 DIODE RD6.8ESB2
D817 8-719-109-97 DIODE RD6.8ESB2
D818 6-500-137-01 DIODE BAT54HT1
D821 8-719-109-97 DIODE RD6.8ESB2
D822 8-719-109-97 DIODE RD6.8ESB2
D824 8-719-056-93 DIODE UDZ-TE-17-18B
D825 8-719-056-93 DIODE UDZ-TE-17-18B
D857 8-719-058-24 DIODE RB501V-40TE-17
D858 8-719-058-24 DIODE RB501V-40TE-17
D901 8-719-056-93 DIODE UDZ-TE-17-18B
D902 8-719-053-18 DIODE 1SR154-400TE-25
D903 8-719-053-18 DIODE 1SR154-400TE-25
D904 6-500-522-01 DIODE 10EDB40-TA1B2
D905 6-500-522-01 DIODE 10EDB40-TA1B2
D906 6-500-522-01 DIODE 10EDB40-TA1B2
D907 6-500-522-01 DIODE 10EDB40-TA1B2
D908 6-500-522-01 DIODE 10EDB40-TA1B2
D909 6-500-522-01 DIODE 10EDB40-TA1B2
D910 8-719-058-24 DIODE RB501V-40TE-17
D911 8-719-056-93 DIODE UDZ-TE-17-18B
D912 8-719-056-93 DIODE UDZ-TE-17-18B
D913 8-719-056-93 DIODE UDZ-TE-17-18B
D914 8-719-056-83 DIODE UDZ-TE-17-6.8B
D915 8-719-056-82 DIODE UDZ-TE-17-6.2B
D916 6-500-522-01 DIODE 10EDB40-TA1B2
D917 6-500-522-01 DIODE 10EDB40-TA1B2
D918 8-719-081-97 DIODE MMDL914T1
D919 8-719-049-38 DIODE 1N5404TU
D921 6-500-522-01 DIODE 10EDB40-TA1B2
D922 6-500-522-01 DIODE 10EDB40-TA1B2
< FERRITE BEAD >
FB701 1-414-760-21 FERRITE, EMI (SMD) (1608)
FB703 1-414-760-21 FERRITE, EMI (SMD) (1608)
< IC >
IC100 6-705-359-02 IC TDA8588AJ/N2/R1
IC401 6-707-303-01 IC TDA7419TR
IC801 6-805-004-01 IC MB90487APF-G-125-BNDE1
IC802 8-759-659-13 IC PST3428UL
IC803 6-705-373-01 IC MM3123DPLE
IC900 6-703-884-01 IC BA8271F-E2
< JUMPER RESISTOR >
JR5 1-216-864-11 SHORT CHIP 0
JR6 1-216-864-11 SHORT CHIP 0
JR10 1-414-227-11 INDUCTOR, FERRITE BEAD
< COIL >
L400 1-414-398-11 INDUCTOR 10uH
L700 1-410-509-11 INDUCTOR 10uH
L701 1-410-501-11 INDUCTOR 2.2uH
L703 1-216-296-11 SHORT CHIP 0
L900 1-456-617-11 COIL, CHOKE
< JACK >
PJ401 1-774-700-41 JACK, PIN 6P (BUS AUDIO IN,
AUDIO OUT REAR/FRONT)
PJ601 1-815-185-13 JACK (ANTENNA)
< TRANSISTOR >
Q400 8-729-421-19 TRANSISTOR UN2213
Q401 8-729-424-08 TRANSISTOR UN2111
Q402 6-551-070-01 TRANSISTOR KRC283S-B-RPK/P
Q403 6-551-070-01 TRANSISTOR KRC283S-B-RPK/P
Q404 6-551-070-01 TRANSISTOR KRC283S-B-RPK/P
Q405 6-551-070-01 TRANSISTOR KRC283S-B-RPK/P
Q406 6-551-070-01 TRANSISTOR KRC283S-B-RPK/P
Q407 6-551-070-01 TRANSISTOR KRC283S-B-RPK/P
Q601 8-729-920-85 TRANSISTOR 2SD1664-QR
Q800 8-729-424-08 TRANSISTOR UN2111
Q801 8-729-421-19 TRANSISTOR UN2213
Q802 8-729-424-08 TRANSISTOR UN2111
Q900 8-729-010-25 TRANSISTOR MSD601-RT1
Q901 8-729-010-25 TRANSISTOR MSD601-RT1
Q902 8-729-421-22 TRANSISTOR UN2211
Q903 8-729-055-96 TRANSISTOR SRC1203SF
Q904 8-729-055-92 TRANSISTOR SRA2203SF
Q905 8-729-055-92 TRANSISTOR SRA2203SF
Q912 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R101 1-216-841-11 METAL CHIP 47K 5% 1/10W
R302 1-216-864-11 SHORT CHIP 0
MAIN
