47
CDX-F5510/F5510X/F5550EE
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R832 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R833 1-249-417-11 CARBON 1K 5% 1/4W
R834 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R844 1-216-845-11 METAL CHIP 100K 5% 1/10W
R846 1-216-845-11 METAL CHIP 100K 5% 1/10W
R847 1-216-864-11 SHORT CHIP 0
R848 1-216-845-11 METAL CHIP 100K 5% 1/10W
R849 1-216-841-11 METAL CHIP 47K 5% 1/10W
R850 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R852 1-216-864-11 SHORT CHIP 0
R853 1-216-864-11 SHORT CHIP 0
R855 1-216-821-11 METAL CHIP 1K 5% 1/10W
R856 1-216-841-11 METAL CHIP 47K 5% 1/10W
R857 1-216-809-11 METAL CHIP 100 5% 1/10W
R858 1-216-809-11 METAL CHIP 100 5% 1/10W
R859 1-216-809-11 METAL CHIP 100 5% 1/10W
R860 1-216-845-11 METAL CHIP 100K 5% 1/10W
R861 1-216-809-11 METAL CHIP 100 5% 1/10W
R862 1-216-809-11 METAL CHIP 100 5% 1/10W
R863 1-216-845-11 METAL CHIP 100K 5% 1/10W
R864 1-216-833-11 METAL CHIP 10K 5% 1/10W
R865 1-216-833-11 METAL CHIP 10K 5% 1/10W
R866 1-216-845-11 METAL CHIP 100K 5% 1/10W
R870 1-249-407-11 CARBON 150 5% 1/4W
R871 1-249-407-11 CARBON 150 5% 1/4W
R872 1-216-029-00 RES-CHIP 150 5% 1/10W
R873 1-216-845-11 METAL CHIP 100K 5% 1/10W
R900 1-216-849-11 METAL CHIP 220K 5% 1/10W
R901 1-216-845-11 METAL CHIP 100K 5% 1/10W
R902 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R903 1-216-841-11 METAL CHIP 47K 5% 1/10W
R904 1-216-841-11 METAL CHIP 47K 5% 1/10W
R905 1-216-833-11 METAL CHIP 10K 5% 1/10W
R907 1-216-833-11 METAL CHIP 10K 5% 1/10W
R908 1-216-809-11 METAL CHIP 100 5% 1/10W
R909 1-216-809-11 METAL CHIP 100 5% 1/10W
R910 1-216-809-11 METAL CHIP 100 5% 1/10W
R911 1-216-864-11 SHORT CHIP 0
R912 1-249-417-11 CARBON 1K 5% 1/4W
R913 1-216-821-11 METAL CHIP 1K 5% 1/10W
R914 1-469-144-21 FERRITE, EMI (SMD) (2012)
R915 1-469-144-21 FERRITE, EMI (SMD) (2012)
R917 1-249-431-11 CARBON 15K 5% 1/4W
R919 1-216-809-11 METAL CHIP 100 5% 1/10W
R920 1-216-821-11 METAL CHIP 1K 5% 1/10W
R921 1-216-809-11 METAL CHIP 100 5% 1/10W
R925 1-216-845-11 METAL CHIP 100K 5% 1/10W
R926 1-216-849-11 METAL CHIP 220K 5% 1/10W
R927 1-216-833-11 METAL CHIP 10K 5% 1/10W
R929 1-216-821-11 METAL CHIP 1K 5% 1/10W
R930 1-216-821-11 METAL CHIP 1K 5% 1/10W
R931 1-216-073-00 RES-CHIP 10K 5% 1/10W
R932 1-216-073-00 RES-CHIP 10K 5% 1/10W
R935 1-216-841-11 METAL CHIP 47K 5% 1/10W
R936 1-216-864-11 SHORT CHIP 0
R938 1-216-073-00 RES-CHIP 10K 5% 1/10W
R939 1-216-073-00 RES-CHIP 10K 5% 1/10W
R940 1-216-845-11 METAL CHIP 100K 5% 1/10W
R941 1-216-837-11 METAL CHIP 22K 5% 1/10W
< SWITCH >
S800 1-571-850-51 SWITCH, SLIDE (FREQUENCY SELECT)
(F5510X)
S801 1-786-458-11 SWITCH, PUSH (1 KEY) (NOSE DET)
S802 1-762-638-21 SWITCH, TACTILE (RESET)
< THERMISTOR (POSITIVE) >
TH900 1-801-792-21 THERMISTOR, POSITIVE
< TUNER >
TUX601 A-3220-961-A TUNER UNIT (TUX-032)
< VIBRATOR >
X800 1-813-524-21 VIBRATOR, CERAMIC (18.432MHz)
X801 1-813-202-11 VIBRATOR, CRYSTAL (32.768kHz)
*************************************************************
RELAY BOARD
************
1-792-173-11 CABLE, FLAT (FFC) 12P (CNP903)
< CAPACITOR >
C974 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C975 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CNP902 1-817-159-11 SOCKET, CONNECTOR 14P
< DIODE >
LED930 6-500-511-01 LED CL-270PG-C-TS (DISC IN) (F5550EE)
LED930 6-500-895-01 LED CL-270UB2-X-TS (DISC IN) (F5510)
LED930 8-719-082-38 LED CL-270SR-C-TS (DISC IN) (F5510X)
LED935 6-500-476-01 LED SML310BA1TT86 (Z) (F5510)
LED935 6-500-510-01 LED CL-195PG-CD-T (Z) (F5550EE)
LED935 8-719-053-09 LED SML-310VTT86 (Z) (F5510X)
< RESISTOR >
R966 1-216-813-11 METAL CHIP 220 5% 1/10W
(F5510)
R966 1-216-817-11 METAL CHIP 470 5% 1/10W
(EXCEPT F5510)
< SWITCH >
S931 1-786-763-11 SWITCH, TACTILE (Z)
*************************************************************
SENSOR BOARD
**************
< SWITCH >
SW2 1-529-566-61 SWITCH, PUSH (1 KEY) (SELF)
SW3 1-529-566-61 SWITCH, PUSH (1 KEY) (DISC IN)
*************************************************************
MAIN SENSORRELAY
