49
CDX-F5510/F5510X/F5550EE
R52 1-218-945-11 RES-CHIP 220 5% 1/16W
R53 1-218-941-81 RES-CHIP 100 5% 1/16W
R54 1-218-941-81 RES-CHIP 100 5% 1/16W
R55 1-218-977-11 RES-CHIP 100K 5% 1/16W
R56 1-218-941-81 RES-CHIP 100 5% 1/16W
R57 1-218-941-81 RES-CHIP 100 5% 1/16W
R58 1-218-941-81 RES-CHIP 100 5% 1/16W
R59 1-218-977-11 RES-CHIP 100K 5% 1/16W
R60 1-218-977-11 RES-CHIP 100K 5% 1/16W
R61 1-218-977-11 RES-CHIP 100K 5% 1/16W
R62 1-218-977-11 RES-CHIP 100K 5% 1/16W
R63 1-218-977-11 RES-CHIP 100K 5% 1/16W
R64 1-218-977-11 RES-CHIP 100K 5% 1/16W
R65 1-218-941-81 RES-CHIP 100 5% 1/16W
R66 1-218-941-81 RES-CHIP 100 5% 1/16W
R67 1-218-941-81 RES-CHIP 100 5% 1/16W
R68 1-218-941-81 RES-CHIP 100 5% 1/16W
R69 1-218-941-81 RES-CHIP 100 5% 1/16W
R70 1-218-941-81 RES-CHIP 100 5% 1/16W
R71 1-220-804-11 RES-CHIP 2.2M 5% 1/16W
R72 1-218-941-81 RES-CHIP 100 5% 1/16W
R73 1-218-973-11 RES-CHIP 47K 5% 1/16W
R74 1-218-941-81 RES-CHIP 100 5% 1/16W
R77 1-218-941-81 RES-CHIP 100 5% 1/16W
R78 1-218-941-81 RES-CHIP 100 5% 1/16W
R80 1-218-941-81 RES-CHIP 100 5% 1/16W
R81 1-218-973-11 RES-CHIP 47K 5% 1/16W
R82 1-218-973-11 RES-CHIP 47K 5% 1/16W
R83 1-218-973-11 RES-CHIP 47K 5% 1/16W
R84 1-218-953-11 RES-CHIP 1K 5% 1/16W
R86 1-218-969-11 RES-CHIP 22K 5% 1/16W
R90 1-218-941-81 RES-CHIP 100 5% 1/16W
R91 1-218-941-81 RES-CHIP 100 5% 1/16W
R100 1-220-200-81 RES-CHIP 30K 5% 1/16W
R101 1-218-971-11 RES-CHIP 33K 5% 1/16W
R112 1-218-990-11 SHORT CHIP 0
R113 1-218-990-11 SHORT CHIP 0
R116 1-218-977-11 RES-CHIP 100K 5% 1/16W
R117 1-218-977-11 RES-CHIP 100K 5% 1/16W
R118 1-218-977-11 RES-CHIP 100K 5% 1/16W
R119 1-218-977-11 RES-CHIP 100K 5% 1/16W
R120 1-218-990-11 SHORT CHIP 0
R121 1-218-990-11 SHORT CHIP 0
R122 1-218-990-11 SHORT CHIP 0
R123 1-218-990-11 SHORT CHIP 0
R125 1-218-941-81 RES-CHIP 100 5% 1/16W
R126 1-218-941-81 RES-CHIP 100 5% 1/16W
R127 1-218-941-81 RES-CHIP 100 5% 1/16W
R128 1-218-941-81 RES-CHIP 100 5% 1/16W
R131 1-216-864-11 SHORT CHIP 0
R132 1-218-962-11 RES-CHIP 5.6K 5% 1/16W
< SWITCH >
SW1 1-529-565-61 SWITCH, PUSH (1 KEY) (DOWN)
< VIBRATOR >
X1 1-813-371-21 VIBRATOR, CERAMIC (12MHz)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
X2 1-795-561-21 VIBRATOR, CERAMIC (16.9344MHz)
*************************************************************
MISCELLANEOUS
***************
11 1-776-207-72 CORD (WITH CONNECTOR) (POWER)
(EXCEPT F5550EE)
11 1-776-527-72 CORD (WITH CONNECTOR) (ISO) (POWER)
(F5550EE)
0153 8-820-207-12 OPTICAL PICK-UP (KSS1000E/K1RP)
154 A-1075-787-A CHASSIS (OP) SUB ASSY (including M901)
F900 1-532-877-11 FUSE (BLADE TYPE) (AUTO FUSE) 10A
M902 A-3337-638-A MOTOR ASSY, SL (SLED)
M903 A-1075-792-A MOTOR ASSY, LE (LOADING)
SW4 1-571-099-11 SWITCH (1 KEY) (LIMIT)
*************************************************************
ACCESSORIES
************
1-479-077-11 REMOTE COMMANDER (RM-X151)
2-515-314-11 MANUAL, INSTRUCTION (ENGLISH,FRENCH)
(F5510)
2-515-314-21 MANUAL, INSTRUCTION (ENGLISH,RUSSIAN)
(F5550EE)
2-515-314-31 MANUAL, INSTRUCTION (ENGLISH,SPANISH,
TRADITIONAL CHINESE) (F5510X)
2-515-317-11 MANUAL, INSTRUCTION, INSTALL (ENGLISH,
FRENCH) (F5510)
2-515-317-21 MANUAL, INSTRUCTION, INSTALL (ENGLISH,
RUSSIAN) (F5550EE)
2-515-317-31 MANUAL, INSTRUCTION, INSTALL (ENGLISH,
SPANISH,TRADITIONAL CHINESE) (F5510X)
2-548-729-01 LID, BATTERY CASE (for RM-X151)
2-584-510-01 CD-ROM (INSTALL) (US)
2-588-850-11 MANUAL, INSTRUCTION
(SONIC STAGE VER. 2.1) (US)
X-3378-390-3 CASE (PANEL) ASSY (for FRONT PANEL)
*************************************************************
SERVO
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par
une marque 0 sont critiques
pour la sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
