Sony CDX-F5510 Service Manual

21
CDX-F5510/F5510X/F5550EE
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R921 1-216-809-11 METAL CHIP 100 5% 1/10W
R925 1-216-845-11 METAL CHIP 100K 5% 1/10W
R926 1-216-849-11 METAL CHIP 220K 5% 1/10W
R927 1-216-833-11 METAL CHIP 10K 5% 1/10W
R929 1-216-821-11 METAL CHIP 1K 5% 1/10W
R930 1-216-821-11 METAL CHIP 1K 5% 1/10W
R931 1-216-073-00 RES-CHIP 10K 5% 1/10W
R932 1-216-073-00 RES-CHIP 10K 5% 1/10W
R935 1-216-841-11 METAL CHIP 47K 5% 1/10W
R936 1-216-864-11 SHORT CHIP 0
R938 1-216-073-00 RES-CHIP 10K 5% 1/10W
R939 1-216-073-00 RES-CHIP 10K 5% 1/10W
R940 1-216-845-11 METAL CHIP 100K 5% 1/10W
R941 1-216-837-11 METAL CHIP 22K 5% 1/10W
< SWITCH >
S801 1-786-458-11 SWITCH, PUSH (1 KEY) (NOSE DET)
S802 1-692-431-21 SWITCH, TACTILE (RESET)
< THERMISTOR (POSITIVE) >
TH900 1-801-792-21 THERMISTOR, POSITIVE
< TUNER UNIT >
TUX601 A-3220-961-B TUNER UNIT (TUX-032)
< VIBRATOR >
X800 1-813-524-21 VIBRATOR, CERAMIC (18.432MHz)
X801 1-813-202-11 VIBRATOR, CRYSTAL (32.768kHz)
*************************************************************
RELAY BOARD
************
< CAPACITOR >
C971 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C972 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C973 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C974 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CNP902 1-817-159-11 SOCKET, CONNECTOR 14P
< DIODE >
LED930 6-500-511-01 LED CL-270PG-C-TS (DOOR IND)
LED931 6-500-510-01 LED CL-195PG-CD-T (Z)
< RESISTOR >
R931 1-216-817-11 METAL CHIP 470 5% 1/10W
< SWITCH >
S931 1-771-884-31 SWITCH, TACTILE (Z)
*************************************************************
SENSOR BOARD
**************
< SWITCH >
SW2 1-529-566-61 SWITCH, PUSH (1 KEY) (SELF)
SW3 1-529-566-61 SWITCH, PUSH (1 KEY) (DISC IN)
*************************************************************
A-1082-772-A SERVO BOARD, COMPLETE
**********************
< CAPACITOR >
C4 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C5 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C6 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C9 1-104-609-11 ELECT CHIP 100uF 20% 4V
C10 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C13 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C16 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C17 1-162-925-11 CERAMIC CHIP 68PF 5% 50V
C18 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C19 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C20 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C21 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C22 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C23 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C24 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C27 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C28 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C29 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C31 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C32 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C33 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C34 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C35 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C36 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C37 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C38 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C39 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C40 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C41 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C42 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C43 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C45 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C47 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C48 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C49 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C51 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C52 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C53 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C57 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C58 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C59 1-126-208-21 ELECT CHIP 47uF 20% 4V
C60 1-112-195-11 ELECT 47uF 20% 4V
C61 1-126-208-21 ELECT CHIP 47uF 20% 4V
C62 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C64 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
MAIN RELAY SENSOR SERVO
