CDX-M3DI/M1000TF
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C8 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C9 1-162-924-11 CERAMIC CHIP 56PF 5% 50V
C10 1-162-924-11 CERAMIC CHIP 56PF 5% 50V
C11 1-162-909-11 CERAMIC CHIP 4PF 0.25PF 50V
C13 1-162-916-11 CERAMIC CHIP 12PF 5% 50V
C14 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C15 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C16 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C17 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C18 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C19 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C20 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C21 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C22 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C23 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C24 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C25 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C27 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C29 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C30 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C34 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C35 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C36 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C38 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C39 1-126-391-11 ELECT CHIP 47uF 20% 6.3V
C40 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C41 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C43 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C44 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C45 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C51 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C53 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C54 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C55 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C56 1-128-934-11 CERAMIC CHIP 0.33uF 20% 10V
C57 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C58 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C59 1-104-609-11 ELECT CHIP 100uF 20% 4V
C60 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C61 1-126-391-11 ELECT CHIP 47uF 20% 6.3V
C62 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C63 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C65 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C67 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C68 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C69 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C70 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C75 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C77 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C78 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C79 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C81 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C102 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C111 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C112 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C113 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C114 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN1 1-815-352-11 CONNECTOR, BOARD TO BOARD 30P
CN2 1-794-153-21 CONNECTOR, FPC (ZIF) 16P
CN3 1-816-275-21 CONNECTOR, FFC/FPC 6P
< FERRITE BEAD >
FB2 1-216-864-11 METAL CHIP 0 5% 1/10W
FB3 1-216-864-11 METAL CHIP 0 5% 1/10W
FB6 1-469-144-21 FERRITE, EMI (SMD)
< IC >
IC1 8-759-699-98 IC uPD63711GC-8EU
IC2 8-759-658-87 IC BA5810FP-E2
IC3 6-703-905-01 IC HD6432238RWN35TEI
IC4 6-702-661-01 IC UT62L1024LC-55LLI
IC5 6-702-153-01 IC CXD9684R-005
IC6 8-759-645-31 IC RN5RZ25BA-TL-FA
IC7 8-759-491-50 IC TC74VHCT244AFT(EL)
IC12 8-759-196-96 IC TC7SH08FU-TE85R
< JUMPER RESISTOR >
JR1 1-216-821-11 METAL CHIP 1K 5% 1/10W
JR3 1-216-864-11 METAL CHIP 0 5% 1/10W
JR5 1-216-821-11 METAL CHIP 1K 5% 1/10W
JR6 1-216-864-11 METAL CHIP 0 5% 1/10W
JR12 1-216-864-11 METAL CHIP 0 5% 1/10W
JR13 1-216-864-11 METAL CHIP 0 5% 1/10W
JR14 1-216-864-11 METAL CHIP 0 5% 1/10W
JR15 1-216-864-11 METAL CHIP 0 5% 1/10W
JR17 1-216-864-11 METAL CHIP 0 5% 1/10W
JR21 1-216-864-11 METAL CHIP 0 5% 1/10W
L4 1-216-001-00 METAL CHIP 10 5% 1/10W
< COIL >
L6 1-469-144-21 FERRITE, EMI (SMD)
L8 1-414-398-11 INDUCTOR 10uH
< TRANSISTOR >
Q1 8-729-904-87 TRANSISTOR 2SB1197K-R
< RESISTOR >
R3 1-216-806-11 METAL CHIP 56 5% 1/10W
R5 1-218-344-11 METAL CHIP 7.5K 5% 1/10W
R7 1-216-839-11 METAL CHIP 33K 5% 1/10W
R8 1-216-833-11 METAL CHIP 10K 5% 1/10W
R9 1-216-840-11 METAL CHIP 39K 5% 1/10W
R10 1-216-835-11 METAL CHIP 15K 5% 1/10W
R12 1-216-837-11 METAL CHIP 22K 5% 1/10W
R13 1-216-807-11 METAL CHIP 68 5% 1/10W
R14 1-216-841-11 METAL CHIP 47K 5% 1/10W
R15 1-216-841-11 METAL CHIP 47K 5% 1/10W
R26 1-216-806-11 METAL CHIP 56 5% 1/10W
R29 1-216-833-11 METAL CHIP 10K 5% 1/10W
R30 1-216-833-11 METAL CHIP 10K 5% 1/10W
R45 1-216-845-11 METAL CHIP 100K 5% 1/10W
R46 1-216-845-11 METAL CHIP 100K 5% 1/10W
SERVO
