CDX-M3DI/M1000TF
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R47 1-216-845-11 METAL CHIP 100K 5% 1/10W
R48 1-216-845-11 METAL CHIP 100K 5% 1/10W
R49 1-216-845-11 METAL CHIP 100K 5% 1/10W
R50 1-216-809-11 METAL CHIP 100 5% 1/10W
R51 1-216-809-11 METAL CHIP 100 5% 1/10W
R52 1-216-809-11 METAL CHIP 100 5% 1/10W
R53 1-216-809-11 METAL CHIP 100 5% 1/10W
R54 1-216-809-11 METAL CHIP 100 5% 1/10W
R55 1-216-809-11 METAL CHIP 100 5% 1/10W
R64 1-216-809-11 METAL CHIP 100 5% 1/10W
R65 1-216-819-11 METAL CHIP 680 5% 1/10W
R67 1-216-845-11 METAL CHIP 100K 5% 1/10W
R68 1-216-857-11 METAL CHIP 1M 5% 1/10W
R69 1-216-813-11 METAL CHIP 220 5% 1/10W
R70 1-216-813-11 METAL CHIP 220 5% 1/10W
R71 1-216-809-11 METAL CHIP 100 5% 1/10W
R72 1-216-809-11 METAL CHIP 100 5% 1/10W
R73 1-216-809-11 METAL CHIP 100 5% 1/10W
R74 1-216-809-11 METAL CHIP 100 5% 1/10W
R75 1-216-809-11 METAL CHIP 100 5% 1/10W
R76 1-216-809-11 METAL CHIP 100 5% 1/10W
R77 1-216-809-11 METAL CHIP 100 5% 1/10W
R78 1-216-809-11 METAL CHIP 100 5% 1/10W
R81 1-216-845-11 METAL CHIP 100K 5% 1/10W
R82 1-216-845-11 METAL CHIP 100K 5% 1/10W
R83 1-216-845-11 METAL CHIP 100K 5% 1/10W
R84 1-216-845-11 METAL CHIP 100K 5% 1/10W
R85 1-216-845-11 METAL CHIP 100K 5% 1/10W
R86 1-216-845-11 METAL CHIP 100K 5% 1/10W
R87 1-216-845-11 METAL CHIP 100K 5% 1/10W
R88 1-216-845-11 METAL CHIP 100K 5% 1/10W
R89 1-216-845-11 METAL CHIP 100K 5% 1/10W
R90 1-216-845-11 METAL CHIP 100K 5% 1/10W
R91 1-216-845-11 METAL CHIP 100K 5% 1/10W
R92 1-216-845-11 METAL CHIP 100K 5% 1/10W
R93 1-216-809-11 METAL CHIP 100 5% 1/10W
R94 1-216-809-11 METAL CHIP 100 5% 1/10W
R95 1-216-809-11 METAL CHIP 100 5% 1/10W
R96 1-216-809-11 METAL CHIP 100 5% 1/10W
R97 1-216-837-11 METAL CHIP 22K 5% 1/10W
R98 1-216-834-11 METAL CHIP 12K 5% 1/10W
R100 1-216-845-11 METAL CHIP 100K 5% 1/10W
R102 1-216-845-11 METAL CHIP 100K 5% 1/10W
R103 1-216-845-11 METAL CHIP 100K 5% 1/10W
R104 1-216-845-11 METAL CHIP 100K 5% 1/10W
R105 1-216-845-11 METAL CHIP 100K 5% 1/10W
R106 1-216-821-11 METAL CHIP 1K 5% 1/10W
R107 1-216-821-11 METAL CHIP 1K 5% 1/10W
R109 1-216-845-11 METAL CHIP 100K 5% 1/10W
R111 1-216-845-11 METAL CHIP 100K 5% 1/10W
R113 1-216-845-11 METAL CHIP 100K 5% 1/10W
R114 1-216-845-11 METAL CHIP 100K 5% 1/10W
R115 1-216-837-11 METAL CHIP 22K 5% 1/10W
R116 1-216-809-11 METAL CHIP 100 5% 1/10W
R117 1-216-809-11 METAL CHIP 100 5% 1/10W
R118 1-216-809-11 METAL CHIP 100 5% 1/10W
R119 1-216-821-11 METAL CHIP 1K 5% 1/10W
R121 1-216-845-11 METAL CHIP 100K 5% 1/10W
R124 1-216-837-11 METAL CHIP 22K 5% 1/10W
R126 1-216-845-11 METAL CHIP 100K 5% 1/10W
R127 1-216-845-11 METAL CHIP 100K 5% 1/10W
R128 1-216-845-11 METAL CHIP 100K 5% 1/10W
R129 1-216-845-11 METAL CHIP 100K 5% 1/10W
R130 1-216-809-11 METAL CHIP 100 5% 1/10W
R131 1-216-809-11 METAL CHIP 100 5% 1/10W
R132 1-216-809-11 METAL CHIP 100 5% 1/10W
R133 1-216-809-11 METAL CHIP 100 5% 1/10W
R134 1-216-809-11 METAL CHIP 100 5% 1/10W
R135 1-216-809-11 METAL CHIP 100 5% 1/10W
R136 1-216-809-11 METAL CHIP 100 5% 1/10W
R142 1-216-815-11 METAL CHIP 330 5% 1/10W
R143 1-218-484-11 METAL CHIP 750 5% 1/10W
R144 1-216-812-11 METAL CHIP 180 5% 1/10W
R145 1-216-817-11 METAL CHIP 470 5% 1/10W
R146 1-216-815-11 METAL CHIP 330 5% 1/10W
R147 1-218-484-11 METAL CHIP 750 5% 1/10W
R148 1-216-809-11 METAL CHIP 100 5% 1/10W
R149 1-216-814-11 METAL CHIP 270 5% 1/10W
R150 1-216-821-11 METAL CHIP 1K 5% 1/10W
R151 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R152 1-216-813-11 METAL CHIP 220 5% 1/10W
R153 1-216-818-11 METAL CHIP 560 5% 1/10W
R154 1-216-809-11 METAL CHIP 100 5% 1/10W
< NETWORK RESISTOR >
RB1 1-233-576-11 RES, CHIP NETWORK 100X4
RB2 1-233-576-11 RES, CHIP NETWORK 100X4
< VIBRATOR >
X1 1-795-520-11 VIBRATOR, CERAMIC (16.9344MHz)
X2 1-795-127-21 VIBRATOR, CERAMIC (12.288MHz)
*************************************************************
A-3340-310-A SWITCH BOARD, COMPLETE
(including S601,S602)
***********************
*************************************************************
MISCELLANEOUS
***************
2 1-776-207-72 CORD (WITH CONNECTOR) (POWER) (M3DI)
2 1-776-527-71 CORD (WITH CONNECTOR) (ISO) (POWER)
(M1000TF)
101 1-688-395-11 FLEXIBLE BOARD
103 1-827-154-11 CABLE, FLEXIBLE FLAT (25 CORE)
301 A-3337-193-A FLOATING BLOCK ASSY (including M901)
307 1-823-951-11 CABLE, FLEXIBLE FLAT (16 CORE)
0 310 8-820-165-06 OPTICAL PICK-UP KSS-721A/C-RP
311 1-676-707-11 PICK-UP FLEXIBLE BOARD
F901 1-532-877-11 FUSE (BLADE TYPE) (AUTO FUSE) 10A
M601 A-3315-488-A MOTOR ASSY (OPEN/CLOSE)
M902 A-3301-985-A MOTOR ASSY, SLED (SLED)
M903 A-3315-039-A MOTOR SUB ASSY, LO (LOADING)
*************************************************************
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
SERVO
SWITCH
