11
CDX-MP80
2-9. MD ASSY
2-8. TRAY (UM) ASSY
1
screw ( M1.7x2.5)
2
screw ( M1.7x2.5)
3
screw ( M1.7x2.5
)
5
tray (UM) assy
4
1
CN3
4
insulator
8
MD assy
5
insulator
6
insulator
7
CN1
3
2
CN2
