52
CDX-MP80
SECTION 6
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in
the parts list may be different from the
parts specified in the diagrams or the
components used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• RESISTORS
All resistors are in ohms.
METAL:Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F:nonflammable
•Abbreviation
CND: Canadian model
• Items marked “*” are not stocked since
they are seldom required for routine service.
Some delay should be anticipated
when ordering these items.
• SEMICONDUCTORS
In each case, u : µ, for example:
uA.. : µA.. uPA.. : µPA..
uPB.. : µPB.. uPC.. : µPC.. uPD.. : µPD..
• CAPACITORS
uF : µF
• COILS
uH : µH
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiques pour
la sécurité.
Ne les remplacer que par une piéce
portant le numéro spécifié.
When indicating parts by reference
number, please include the board.
KEY
KEY BOARD
**********
1-694-903-11 CONDUCTIVE BOARD, CONNECTION
* 3-227-280-01 CASE (IR-T), SHIELD
* 3-227-281-02 CASE (IR-B), SHIELD
3-236-989-01 PLATE (LCD), LIGHT GUIDE
3-236-990-01 PLATE (LCD), GROUND
3-236-991-01 HOLDER (LCD)
3-236-992-01 SHEET (DIFFUSION)
3-242-787-01 PLATE (IR), INSULATED
< CAPACITOR >
C900 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C901 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C903 1-135-852-21 ELECT CHIP 22uF 20% 6.3V
C904 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C905 1-135-852-21 ELECT CHIP 22uF 20% 6.3V
C906 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C907 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C908 1-125-891-11 CERAMIC CHIP 0.47uF 10% 10V
C909 1-135-852-21 ELECT CHIP 22uF 20% 6.3V
C910 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C911 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C912 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C913 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C982 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C983 1-115-412-11 CERAMIC CHIP 680PF 5% 25V
C986 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C990 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C991 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C992 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C993 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN901 1-778-183-11 PLUG, CONNECTOR 18P
< DIODE >
D900 8-719-420-90 DIODE MA8051-M
D901 8-719-423-32 DIODE MA8120-M
D902 8-719-422-64 DIODE MA8062-M
D903 8-719-422-64 DIODE MA8062-M
D904 8-719-422-64 DIODE MA8062-M
D906 8-719-422-64 DIODE MA8062-M
D907 8-719-422-64 DIODE MA8062-M
D908 8-719-422-64 DIODE MA8062-M
D910 8-719-404-50 DIODE MA111-TX
D972 8-719-422-64 DIODE MA8062-M
D974 8-719-420-14 DIODE MA8082-M
< ROTARY ENCODER >
ENC901 1-475-235-31 ENCODER, ROTARY (VOL/SOUND)
ENC902 1-475-235-31 ENCODER, ROTARY (ENTER,
. –/+ > (AMS/PRESET))
< FERRITE BEAD >
FB901 1-414-921-11 INDUCTOR, FERRITE BEAD
FB902 1-414-921-11 INDUCTOR, FERRITE BEAD
< IC >
IC901 8-759-653-26 IC LC75878W
IC902 8-759-830-18 IC RRX9000-0601#1
IC903 8-759-830-17 IC RRX9000-0401R#01
< LIQUID CRYSTAL DISPLAY >
LCD901 1-804-644-11 DISPLAY PANEL, LIQUID CRYSTAL
< DIODE >
LED900 8-719-083-14 LED RRX9000-0501 (IR RECEIVE)
LED901 8-719-061-16 LED CL-190SR-CD-T (LIST)
LED902 8-719-061-16 LED CL-190SR-CD-T (REP)
LED904 8-719-061-16 LED CL-190SR-CD-T (VOL)
LED905 8-719-061-16 LED CL-190SR-CD-T (VOL)
LED906 8-719-061-16 LED CL-190SR-CD-T (VOL)
LED907 8-719-061-16 LED CL-190SR-CD-T
(. –/+ > (AMS/PRESET))
LED908 8-719-061-16 LED CL-190SR-CD-T
(. –/+ > (AMS/PRESET))
LED909 8-719-061-16 LED CL-190SR-CD-T
(. –/+ > (AMS/PRESET))
LED911 6-500-558-01 LED HL500Z01SS (LCD BACK LIGHT)
LED912 6-500-558-01 LED HL500Z01SS (LCD BACK LIGHT)
LED913 6-500-558-01 LED HL500Z01SS (LCD BACK LIGHT)
LED918 8-719-061-16 LED CL-190SR-CD-T (MENU)
LED919 8-719-061-16 LED CL-190SR-CD-T (DSPL)
< SWITCH >
LSW901 1-771-883-11 SWITCH, TACTILE (WITH LED) (OFF)
LSW902 1-771-476-11 SWITCH, KEYBOARD (WITH LED) (MODE)
LSW903 1-771-476-11 SWITCH, KEYBOARD (WITH LED) (SEEK –)
To Next Page
