9
CDX-MP80
2-5. MAIN BOARD
2-4. CAM BLOCK ASSY, MOTOR BLOCK ASSY
1
PTT 2.6x6
5
cover (protection)
4
PTT 2.6x6
6
motor block assy
2
cam block assy
3
CN602
4
PTT 2.6x6
ground point
3
PTT 2.6x6
ground point
1
PTT 2.6x6
5
MAIN board
2
PTT 2.6x
6
