Sony CMT-DF1 Service Manual

2727
HCD-DF1
HCD-DF1
7-15. SCHEMATIC DIAGRAM – POWER SUPPLY Section –
(Page 21)
CN14
F3
F2
CON501
T3
T2
T1
SW2
CON10
J506
J501J502
J503
J505 J507
J504
F1
SW1
4P
T2AL
250V
T2AL 250V
T0.63AL
250V
2P
2P
(AC IN)
14V
14V
9V
9V
POWER TRANSFORMER
-1-2
VOLTAGE
SELECTOR
120V 220V 230-240V
(E,HK,SP)
(AEP,RU,E,HK,SP,TW,KR)
(TW)
(KR)
(AEP,RU,E,HK,KR,AUS)
(AUS)
(AEP,RU,E,HK,SP,TW,KR)
(AUS)
(AEP,RU,AUS)
POWER
2
1

Sony CMT-DF1 Specifications

General

Bass reflex	Yes
Speaker type	1-way
RMS rated power	10 W
Number of speakers	2
Mid-range driver diameter	100 mm
Total Harmonic Distortion (THD)	10 %
Type	Home audio micro system
Cassette deck	No
Product color	Gray
Disc types supported	CD, CD-R, CD-RW, DVD, DVD+R, DVD+RW, DVD-R, DVD-RW
Supported radio bands	AM, FM
Preset stations quantity	40
Display type	LCD
Speaker depth	187 mm
Speaker width	145 mm
Speaker height	212 mm
Video recording	-
Apple docking compatibility	Not supported
Headphone outputs	1
Power source	AC

Weight and Dimensions

Depth	201 mm
Width	169 mm
Height	218 mm
