SERVICE MANUAL
DVD DECK RECEIVER
HCD-DF1
SPECIFICATIONS
9-887-738-02
2007J05-1
© 2007.10
Sony Corporation
Audio Business Group
Published by Sony Techno Create Corporation
• HCD-DF1 is the amplifier, disc player, tape deck
and tuner section in CMT-DF1.
DVD Model Name Using Similar Mechanism NEW
Section Optical Pick-up Block Name KHM-313AHC
Tape deck Model Name Using Similar Mechanism NEW
Section Tape Transport Mechanism Type H-21
– Continued on next page –
• This system incorporates Dolby
1)
Digital and DTS
2)
Surround System.
1)
Manufactured under license from Dolby Laboratories.
“Dolby” and the double-D symbol are trademarks of Dolby
Laboratories.
2)
Manufactured under license from Digital Theater Systems, Inc.
“DTS” and “DTS 2.0 + Digital Out” are trademarks of Digital
Theater Systems, Inc.
• MPEG Layer-3 audio coding technology and patents licensed
from Fraunhofer IIS and Thomson.
• DivX is a video file compression technology, developed by
®
developed by DivX, Inc.
DivX, DivX Certified, and associated logos are trademarks of
DivX, Inc. and are used under license.
Digital
Amplifier section
European and Russian models:
DIN power output (rated): 3.6 + 3.6 watts (4 ohms
at 1kHz, DIN)
Continuous RMS power output (reference):
5 + 5 watts (4 ohms at
1 kHz, 10% THD)
Music power output (reference):
8 + 8 watts (4 ohms at
1 kHz, 10% THD)
Other models:
The following measured at AC 120 V, 220 V,
240 V, 50/60 Hz
DIN power output (rated): 3.6 + 3.6 watts
(4 ohms at 1 kHz, DIN)
Continuous RMS power output (reference):
5 + 5 watts
(4 ohms at 1 kHz, 10%
THD)
Inputs
MIC (monaural mini jack): sensitivity 1.5 mV,
impedance 10 kilohms
Outputs
VIDEO OUT (phono jack):
max. output level
1 Vp-p, unbalanced,
Sync negative, load
impedance 75 ohms
S VIDEO OUT (4-pin/mini-DIN jack):
Y: 1 Vp-p, unbalanced,
Sync negative,
C: 0.286 Vp-p, load
impedance 75 ohms
COMPONENT VIDEO OUT:
Y: 1 Vp-p, 75 ohms
P
B , P R : 0.7 Vp-p,
75 ohms
DIGITAL OUT (OPTICAL) (Square optical
connector jack, rear panel)
Wavelength 660 nm
PHONES (stereo mini jack):
accepts headphones of
8 ohms or more
SPEAKER: accepts impedance of
4 ohms
Disc player section
System Compact disc and
digital audio and video
system
Laser Laser Diode Properties
• Emission duration:
continuous
• Laser Output*:
Less than 1,000 µW
* This output is the
value measurement
at a distance of
200mm from the
objective lens surface
on the Optical Pick-up
Block with 7mm
aperture.
Semiconductor laser
(DVD: λ=650 nm,
CD: λ=790 nm)
