Sony CMT-DF1 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
37
HCD-DF1
DECK
R179 1-216-841-11 METAL CHIP 47K 5% 1/10W
R180 1-216-841-11 METAL CHIP 47K 5% 1/10W
R181 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R182 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R183 1-216-849-11 METAL CHIP 220K 5% 1/10W
R184 1-249-401-11 CARBON 47 5% 1/4W
R185 1-216-849-11 METAL CHIP 220K 5% 1/10W
R186 1-216-849-11 METAL CHIP 220K 5% 1/10W
R187 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R188 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R193 1-249-417-11 CARBON 1K 5% 1/4W
R194 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R195 1-216-837-11 METAL CHIP 22K 5% 1/10W
R196 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R197 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
RJ100 1-216-296-11 SHORT CHIP 0
< SWITCH >
SW5 1-798-081-11 SWITCH, SLIDE (REC/PB)
< TRANSFORMER >
T101 1-445-263-11 TRANSFORMER, BIAS OSCILLATION
< DIODE >
ZD5 8-719-109-97 DIODE RD6.8ESB2
************************************************************
X-2187-514-1 DVD BOARD, COMPLETE (for SERVICE)
(AEP, E)
X-2187-515-1 DVD BOARD, COMPLETE (for SERVICE) (AUS)
X-2187-516-1 DVD BOARD, COMPLETE (for SERVICE)
(HK, KR, SP, TW)
X-2187-517-1 DVD BOARD, COMPLETE (for SERVICE) (RU)
********************
When DVD board is defective, exchange the entire mounted board.
************************************************************
MAIN BOARD
***********
1-834-248-21 WIRE, FLAT TYPE (9 CORE)
7-685-646-79 SCREW +BVTP 3X8 TYPE2 IT-3
< CAPACITOR >
C1 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C2 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C3 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C4 1-104-662-91 ELECT 22uF 20% 25V
C5 1-164-160-11 CERAMIC CHIP 20PF 5% 50V
C6 1-164-160-11 CERAMIC CHIP 20PF 5% 50V
C7 1-126-934-11 ELECT 220uF 20% 16V
C8 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C10 1-104-662-91 ELECT 22uF 20% 25V
C11 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C12 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C13 1-126-934-11 ELECT 220uF 20% 16V
C14 1-126-964-11 ELECT 10uF 20% 50V
C15 1-126-933-11 ELECT 100uF 20% 16V
C16 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C17 1-126-935-11 ELECT 470uF 20% 16V
C18 1-126-934-11 ELECT 220uF 20% 16V
C19 1-126-935-11 ELECT 470uF 20% 16V
C20 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C21 1-126-934-11 ELECT 220uF 20% 16V
C22 1-126-935-11 ELECT 470uF 20% 16V
C23 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C24 1-104-700-11 CERAMIC CHIP 0.027uF 10% 16V
C25 1-104-700-11 CERAMIC CHIP 0.027uF 10% 16V
C26 1-126-961-11 ELECT 2.2uF 20% 50V
C27 1-126-963-11 ELECT 4.7uF 20% 50V
C28 1-126-963-11 ELECT 4.7uF 20% 50V
C29 1-126-961-11 ELECT 2.2uF 20% 50V
C30 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C31 1-126-961-11 ELECT 2.2uF 20% 50V
C32 1-126-961-11 ELECT 2.2uF 20% 50V
C33 1-126-961-11 ELECT 2.2uF 20% 50V
C34 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C35 1-126-961-11 ELECT 2.2uF 20% 50V
C36 1-126-961-11 ELECT 2.2uF 20% 50V
C37 1-126-961-11 ELECT 2.2uF 20% 50V
C38 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C39 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C40 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C41 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C42 1-126-963-11 ELECT 4.7uF 20% 50V
C43 1-126-963-11 ELECT 4.7uF 20% 50V
C46 1-126-964-11 ELECT 10uF 20% 50V
C47 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C48 1-126-960-11 ELECT 1uF 20% 50V
C49 1-126-960-11 ELECT 1uF 20% 50V
C50 1-126-960-11 ELECT 1uF 20% 50V
C51 1-126-960-11 ELECT 1uF 20% 50V
C52 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C53 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C54 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C55 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C56 1-126-963-11 ELECT 4.7uF 20% 50V
C57 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C58 1-104-662-91 ELECT 22uF 20% 25V
C59 1-126-959-11 ELECT 0.47uF 20% 50V
C60 1-126-959-11 ELECT 0.47uF 20% 50V
C61 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C62 1-164-230-11 CERAMIC CHIP 220PF 5% 50V
C63 1-126-933-11 ELECT 100uF 20% 16V
C65 1-126-944-11 ELECT 3300uF 20% 25V
C66 1-126-767-11 ELECT 1000uF 20% 16V
C67 1-126-767-11 ELECT 1000uF 20% 16V
C68 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C69 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C70 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C71 1-126-933-11 ELECT 100uF 20% 16V
C72 1-126-963-11 ELECT 4.7uF 20% 50V
C73 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C74 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C75 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C76 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
DVD MAIN
Ver. 1.3

Sony CMT-DF1 Specifications

General

Bass reflex	Yes
Speaker type	1-way
RMS rated power	10 W
Number of speakers	2
Mid-range driver diameter	100 mm
Total Harmonic Distortion (THD)	10 %
Type	Home audio micro system
Cassette deck	No
Product color	Gray
Disc types supported	CD, CD-R, CD-RW, DVD, DVD+R, DVD+RW, DVD-R, DVD-RW
Supported radio bands	AM, FM
Preset stations quantity	40
Display type	LCD
Speaker depth	187 mm
Speaker width	145 mm
Speaker height	212 mm
Video recording	-
Apple docking compatibility	Not supported
Headphone outputs	1
Power source	AC

Weight and Dimensions

Depth	201 mm
Width	169 mm
Height	218 mm
