Sony CMT-DF1 Service Manual

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
41
HCD-DF1
MICROPHONE
< JACK >
JA302 1-815-629-11 JACK (PHONES)
JA303 1-815-629-11 JACK (MIC)
< TRANSISTOR >
Q301 8-729-120-28 TRANSISTOR 2SC1623-L5L6
< RESISTOR >
R301 1-216-814-11 METAL CHIP 270 5% 1/10W
R302 1-216-814-11 METAL CHIP 270 5% 1/10W
R303 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R304 1-216-845-11 METAL CHIP 100K 5% 1/10W
R305 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R306 1-216-845-11 METAL CHIP 100K 5% 1/10W
R307 1-216-814-11 METAL CHIP 270 5% 1/10W
R308 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R309 1-216-845-11 METAL CHIP 100K 5% 1/10W
R310 1-216-837-11 METAL CHIP 22K 5% 1/10W
R311 1-216-838-11 METAL CHIP 27K 5% 1/10W
R313 1-216-845-11 METAL CHIP 100K 5% 1/10W
R314 1-216-817-11 METAL CHIP 470 5% 1/10W
R315 1-216-809-11 METAL CHIP 100 5% 1/10W
R316 1-216-832-11 METAL CHIP 8.2K 5% 1/10W
R317 1-216-833-11 METAL CHIP 10K 5% 1/10W
< VARIABLE RESISTOR >
VR301 1-227-788-11 RES, VAR, CARBON 20K (MIC LEVEL)
************************************************************
A-1283-893-A PANEL BOARD, COMPLETE
**********************
< CAPACITOR >
C200 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C201 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C202 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C212 1-126-933-11 ELECT 100uF 20% 16V
C215 1-126-933-11 ELECT 100uF 20% 16V
C216 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C217 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C218 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C219 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C220 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C221 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C222 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C223 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C224 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< FLAT CABLE >
CON11 1-831-615-21 CABLE, FLEXIBLE FLAT (12 CORE)
< IC >
IC2 8-759-465-98 IC BU9728AKV-E2
IC5 6-600-309-01 IC RPM7240-H9
< RESISTOR>
J207 1-249-409-11 CARBON 220 5% 1/4W
< SWITCH >
KEY1 1-762-875-21 SWITCH, KEYBOARD (x)
KEY2 1-762-875-21 SWITCH, KEYBOARD (TUNING –, l m)
KEY3 1-762-875-21 SWITCH, KEYBOARD (u)
KEY4 1-762-875-21 SWITCH, KEYBOARD (TUNING +, M L)
KEY5 1-762-875-21 SWITCH, KEYBOARD (DSGX)
KEY6 1-762-875-21 SWITCH, KEYBOARD (PROGRESSIVE)
KEY7 1-762-875-21 SWITCH, KEYBOARD (VOLUME –)
KEY8 1-762-875-21 SWITCH, KEYBOARD (VOLUME +)
KEY9 1-762-875-21 SWITCH, KEYBOARD (FUNCTION)
KEY10 1-762-875-21 SWITCH, KEYBOARD (TUNER/BAND)
KEY11 1-762-875-21 SWITCH, KEYBOARD (DISPLAY)
< LED >
LED1 6-502-156-01 LED 1L2345B22EOCH001 (LCD BACK LIGHT)
LED2 6-502-156-01 LED 1L2345B22EOCH001 (LCD BACK LIGHT)
LED3 6-501-980-01 LED 1L0341H11AODA201 (STANDBY)
< RESISTOR >
R201 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R203 1-216-864-11 SHORT CHIP 0
R204 1-249-409-11 CARBON 220 5% 1/4W
R239 1-216-821-11 METAL CHIP 1K 5% 1/10W
R240 1-216-809-11 METAL CHIP 100 5% 1/10W
R246 1-216-833-11 METAL CHIP 10K 5% 1/10W
R247 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R248 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R250 1-216-833-11 METAL CHIP 10K 5% 1/10W
R251 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R252 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R253 1-216-809-11 METAL CHIP 100 5% 1/10W
R254 1-216-833-11 METAL CHIP 10K 5% 1/10W
R255 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R256 1-216-823-11 METAL CHIP 1.5K 5% 1/10W
R257 1-216-809-11 METAL CHIP 100 5% 1/10W
R260 1-216-864-11 SHORT CHIP 0
R261 1-216-857-11 METAL CHIP 1M 5% 1/10W
R262 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R263 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R264 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R265 1-216-865-11 METAL CHIP 3K 5% 1/10W
R266 1-216-853-11 METAL CHIP 470K 5% 1/10W
R267 1-216-864-11 SHORT CHIP 0
************************************************************
POWER BOARD
*************
< CONNECTOR >
CN14 1-815-445-11 PIN, CONNECTOR (PWB) 4P
CON10 1-564-321-00 PIN, CONNECTOR (3.96mm PITCH) 2P
(EXCEPT AUS)
* CON501 1-568-226-11 PIN, CONNECTOR (3.96mm PITCH) 2P (AUS)
PANEL POWER

Sony CMT-DF1 Specifications

General

Bass reflex	Yes
Speaker type	1-way
RMS rated power	10 W
Number of speakers	2
Mid-range driver diameter	100 mm
Total Harmonic Distortion (THD)	10 %
Type	Home audio micro system
Cassette deck	No
Product color	Gray
Disc types supported	CD, CD-R, CD-RW, DVD, DVD+R, DVD+RW, DVD-R, DVD-RW
Supported radio bands	AM, FM
Preset stations quantity	40
Display type	LCD
Speaker depth	187 mm
Speaker width	145 mm
Speaker height	212 mm
Video recording	-
Apple docking compatibility	Not supported
Headphone outputs	1
Power source	AC

Weight and Dimensions

Depth	201 mm
Width	169 mm
Height	218 mm
