Sony CMT-DF1 Service Manual

SERVICE MANUAL
SPECIFICATIONS
Speaker system Full range, bass-reflex
type, magnetically
shielded type
Speaker units
Full range: 10 cm, cone type
Nominal impedance 4 ohms
Dimensions (w/h/d) Approx. 145 × 212 ×
187 mm
Mass Approx. 1.4 kg net per
speaker
Design and specifications are subject to
change without notice.
SPEAKER SYSTEM
AEP Model
E Model
Australian Model
SS-CDF1
Ver. 1.2 2007.06
9-887-737-01
2007F05-1
© 2007.06
Sony Corporation
Personal Audio Division
Published by Sony Techno Create Corporation
• SS-CDF1 is the speaker system in CMT-DF1.
PARTS LIST
Part No. Description Remark
A-1283-796-A OVERALL ASSY

Sony CMT-DF1 Specifications

General

Bass reflex	Yes
Speaker type	1-way
RMS rated power	10 W
Number of speakers	2
Mid-range driver diameter	100 mm
Total Harmonic Distortion (THD)	10 %
Type	Home audio micro system
Cassette deck	No
Product color	Gray
Disc types supported	CD, CD-R, CD-RW, DVD, DVD+R, DVD+RW, DVD-R, DVD-RW
Supported radio bands	AM, FM
Preset stations quantity	40
Display type	LCD
Speaker depth	187 mm
Speaker width	145 mm
Speaker height	212 mm
Video recording	-
Apple docking compatibility	Not supported
Headphone outputs	1
Power source	AC

Weight and Dimensions

Depth	201 mm
Width	169 mm
Height	218 mm
