71
GB
Precautions/Specifications
Specifications
Main unit
AUDIO POWER SPECIFICATIONS
POWER OUTPUT AND TOTAL HARMONIC
DISTORTION:
(The United States model only)
With 6 ohm loads, both channels driven, from
120 Hz – 10,000 Hz; rated 50 watts per channel
minimum RMS power, with no more than 10%
total harmonic distortion from 250 milliwatts to
rated output.
Amplifier section
European models:
Power output (rated):
40 watts + 40 watts (6 ohms at 1 kHz, 1% THD)
Continuous RMS power output (reference):
50 watts + 50 watts (6 ohms at 1 kHz, 10% THD)
Music power output (reference):
60 watts + 60 watts (6 ohms at 1 kHz, 10% THD)
Australian model:
Power output (rated):
40 watts + 40 watts (6 ohms at 1 kHz, 1% THD)
Continuous RMS power output (reference):
50 watts + 50 watts (6 ohms at 1 kHz, 10% THD)
Other models:
Power output (rated):
35 watts + 35 watts (6 ohms at 1 kHz, 1% THD)
Continuous RMS power output (reference):
43 watts + 43 watts (6 ohms at 1 kHz, 10% THD)
Wireless LAN section
Compatible standards:
IEEE 802.11 b/g (WEP 64 bit, WEP 128 bit,
WPA/WPA2-PSK (AES), WPA/WPA2-PSK
(TKIP))
Radio frequency:
2.4 GHz
CD player section
System:
Compact disc and digital audio system
Laser Diode Properties
Emission Duration: Continuous
Laser Output*: Less than 44.6µW
* This output is the value measurement at a distance of
200mm from the objective lens surface on the Optical
Pick-up Block with 7mm aperture.
Frequency response:
20 Hz – 20 kHz
Signal-to-noise ratio:
More than 90 dB
Dynamic range:
More than 90 dB
Tuner section
AM tuner section:
Tuning range:
European model:
531 kHz – 1,602 kHz (with 9 kHz tuning interval)
Other models:
530 kHz – 1,710 kHz (with 10 kHz tuning interval)
531 kHz – 1,710 kHz (with 9 kHz tuning interval)
Antenna:
AM loop antenna
Intermediate frequency:
400 kHz
FM tuner section:
FM stereo, FM superheterodyne tuner
Tuning range:
87.5 MHz – 108.0 MHz (50 kHz step)
Antenna:
FM lead antenna
Antenna terminals:
75 ohms unbalanced
To Next Page
