Sony CPD-E530 - Section 6: Electrical Parts List; H1 Board, Mounted

*
Items marked with an asterisk are not stocked since they
are seldom required for routine service. Expect some delay
when ordering these components.
RESISTORS
• All resistors are in ohms
• F : nonammable
• All variable and adjustable resistors
have characteristic curve B, unless
otherwise noted.
REF. NO. PART NO. DESCRIPTION VALUES
The components in this manual identied by the following
symbol:
indicate parts that have been carefully factory-
selected to satisfy regulations regarding X-ray radiation for
each set.
Should replacement be required for one of these
components, replace only with the value originally used.
NOTE: The components identied by shading
and
!
mark are critical for safety. Replace only
with part number specied.
NOTE: Les composants identies per un trame et
une marque
!
sont critiques pour la securite.
Ne les remplacer que par une piece portant le
numero specie.
When ordering parts by reference
number, please include the board name.
REF. NO. PART NO. DESCRIPTION VALUES
H1
SECTION 6: ELECTRICAL PARTS LIST
H1
* A-1372-926-A H1 BOARD, MOUNTED
CAPACITOR
C1400 1-126-795-11 ELECT 10µF 20% 50V
C1401 1-126-786-11 ELECT 47µF 20% 16V
C1402 1-126-786-11 ELECT 47µF 20% 16V
C1403 1-137-150-11 FILM 0.01µF 5% 100V
C1404 1-137-150-11 FILM 0.01µF 5% 100V
C1405 1-126-786-11 ELECT 47µF 20% 16V
C1407 1-126-786-11 ELECT 47µF 20% 16V
C1498 1-130-495-00 MYLAR 0.1µF 5% 50V
CONNECTOR
CN1400 1-564-593-11 PLUG, CONNECTOR 14P
* CN1401 1-564-520-11 PLUG, CONNECTOR 5P
DIODE
D1400 8-719-080-89 DIODE SPR-325MYTT31
D1402 8-719-911-19 DIODE 1SS119-25
D1403 8-719-911-19 DIODE 1SS119-25
FERRITE BEAD
FB1401 1-412-911-11 FERRITE 0µH
FB1402 1-412-911-11 FERRITE 0µH
FB1403 1-412-911-11 FERRITE 0µH
TRANSISTOR
Q1400 8-729-029-66 TRANSISTOR DTC114ESA
Q1401 8-729-029-68 TRANSISTOR DTC114TSA
Q1402 8-729-029-40 TRANSISTOR DTA124ESA
RESISTOR
R1400 1-215-405-00 METAL 220 1% 1/4W
R1401 1-215-405-00 METAL 220 1% 1/4W
R1402 1-215-397-00 METAL 100 1% 1/4W
R1403 1-215-397-00 METAL 100 1% 1/4W
R1404 1-215-413-00 METAL 470 1% 1/4W
R1405 1-249-441-11 CARBON 100K 5% 1/4W
R1406 1-249-407-11 CARBON 150 5% 1/4W
R1407 1-249-409-11 CARBON 220 5% 1/4W
R1408 1-249-413-11 CARBON 470 5% 1/4W
R1409 1-249-441-11 CARBON 100K 5% 1/4W
R1419 1-249-441-11 CARBON 100K 5% 1/4W
R1420 1-249-429-11 CARBON 10K 5% 1/4W
R1421 1-215-445-00 METAL 10K 1% 1/4W
R1422 1-249-433-11 CARBON 22K 5% 1/4W
R1423 1-249-433-11 CARBON 22K 5% 1/4W
R1424 1-215-453-00 METAL 22K 1% 1/4W
SWITCH
S1400 1-762-196-21 SWITCH, TACTILE
S1401 1-762-196-21 SWITCH, TACTILE
S1402 1-771-734-11 SWITCH, TACTILE
S1403 1-571-427-11 SWITCH, SLIDE
THERMISTOR
TH1400 1-807-796-11 THERMISTOR
— 36 —
CPD-E530
