Sony CPD-E530 - A1 Board, Complete

REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
A1
* A-1299-419-A A1 BOARD, COMPLETE
4-382-854-11 SCREW (M3X10), P, SW (+)
CAPACITOR
C001 1-162-318-11 CERAMIC 0.001µF 10% 500V
C004 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C005 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C007 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V
C009 1-126-960-11 ELECT 1µF 20% 50V
C010 1-126-947-11 ELECT 47µF 20% 35V
C011 1-106-220-00 MYLAR 0.1µF 10% 100V
C012 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V
C014 1-107-930-91 ELECT 22µF 20% 100V
C015 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C016 1-128-528-11 ELECT 470µF 20% 25V
C017 1-163-251-11 CERAMIC CHIP 100pF 5% 50V
C018 1-107-649-11 ELECT 2.2µF 20% 250V
C019 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C021 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C022 1-126-947-11 ELECT 47µF 20% 35V
C023 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V
C024 1-107-909-11 ELECT 47µF 20% 50V
C025 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C026 1-163-227-11 CERAMIC CHIP 10pF 0.50pF 50V
C027 1-126-785-11 ELECT 47µF 20% 10V
C029 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V
C031 1-162-318-11 CERAMIC 0.001µF 10% 500V
C032 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C033 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C035 1-104-574-11 CERAMIC 0.0047µF 10% 2KV
C036 1-163-251-11 CERAMIC CHIP 100pF 5% 50V
C037 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C038 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V
C039 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
C040 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C042 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
C043 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C045 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C046 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C048 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C049 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C050 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
C051 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
C053 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C054 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C055 1-163-235-11 CERAMIC CHIP 22pF 5% 50V
C057 1-126-947-11 ELECT 47µF 20% 35V
C058 1-163-224-11 CERAMIC CHIP 7pF 0.25pF 50V
C059 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C061 1-163-255-11 CERAMIC CHIP 150pF 5% 50V
C062 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C063 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C064 1-126-382-11 ELECT 100µF 20% 16V
C065 1-107-882-91 ELECT 100µF 20% 16V
C090 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C091 1-126-960-11 ELECT 1µF 20% 50V
C092 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C101 1-163-233-91 CERAMIC CHIP 18pF 5% 50V
C105 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C106 1-137-857-21 MYLAR 0.47µF 10% 250V
C108 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V
C109 1-126-947-11 ELECT 47µF 20% 35V
C111 1-163-251-11 CERAMIC CHIP 100pF 5% 50V
C120 1-126-947-11 ELECT 47µF 20% 35V
C123 1-136-189-00 MYLAR 0.1µF 10% 250V
C130 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V
C152 1-126-947-11 ELECT 47µF 20% 35V
C201 1-163-233-91 CERAMIC CHIP 18pF 5% 50V
C205 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C206 1-137-857-21 MYLAR 0.47µF 10% 250V
C208 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V
C211 1-163-251-11 CERAMIC CHIP 100pF 5% 50V
C220 1-126-947-11 ELECT 47µF 20% 35V
C223 1-136-189-00 MYLAR 0.1µF 10% 250V
C230 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V
C252 1-126-947-11 ELECT 47µF 20% 35V
C301 1-163-231-11 CERAMIC CHIP 15pF 5% 50V
C305 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C306 1-137-857-21 MYLAR 0.47µF 10% 250V
C308 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V
C311 1-163-251-11 CERAMIC CHIP 100pF 5% 50V
C319 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
A1
— 37 —
CPD-E530
