Sony CPD-E530 - Page 38

REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identied by shading
and
!
mark are critical for safety. Replace only
with part number specied.
NOTE: Les composants identies per un trame et une
marque
!
sont critiques pour la securite. Ne les
remplacer que par une piece portant le numero specie.
C320 1-126-947-11 ELECT 47µF 20% 35V
C323 1-136-189-00 MYLAR 0.1µF 10% 250V
C330 1-164-489-11 CERAMIC CHIP 0.22µF 10% 16V
C352 1-126-947-11 ELECT 47µF 20% 35V
CONNECTOR
CN303 1-695-915-11 TAB (CONTACT)
CN307 1-794-991-11 CONNECTOR, D SUB
CN309 1-794-991-11 CONNECTOR, D SUB
* CN315 1-778-682-11 PIN, CONNECTOR (PC BOARD) 8P
CN318 1-764-101-11 PIN, CONNECTOR (PC BOARD) 2P
DIODE
D001 8-719-801-78 DIODE 1SS184
D002 8-719-109-89 DIODE RD5.6ESB2
D003 8-719-109-89 DIODE RD5.6ESB2
D004 8-719-062-51 DIODE 1PS226-115
D005 8-719-062-51 DIODE 1PS226-115
D006 8-719-801-78 DIODE 1SS184
D007 8-719-109-89 DIODE RD5.6ESB2
D008 8-719-109-89 DIODE RD5.6ESB2
D009 8-719-109-89 DIODE RD5.6ESB2
D010 8-719-109-89 DIODE RD5.6ESB2
D011 8-719-109-89 DIODE RD5.6ESB2
D012 8-719-062-51 DIODE 1PS226-115
D013 8-719-911-19 DIODE 1SS119-25
D014 8-719-911-19 DIODE 1SS119-25
D016 8-719-109-89 DIODE RD5.6ESB2
D019 8-719-062-51 DIODE 1PS226-115
D101 8-719-062-51 DIODE 1PS226-115
D104 8-719-052-12 DIODE 1SS376TE-17
D105 8-719-052-12 DIODE 1SS376TE-17
D106 8-719-970-83 DIODE HSS82-TJ
D108 8-719-066-10 DIODE 1PS181-115
D111 8-719-062-51 DIODE 1PS226-115
D201 8-719-062-51 DIODE 1PS226-115
D204 8-719-052-12 DIODE 1SS376TE-17
D205 8-719-052-12 DIODE 1SS376TE-17
D206 8-719-970-83 DIODE HSS82-TJ
D208 8-719-066-10 DIODE 1PS181-115
D211 8-719-062-51 DIODE 1PS226-115
D301 8-719-062-51 DIODE 1PS226-115
D304 8-719-052-12 DIODE 1SS376TE-17
D305 8-719-052-12 DIODE 1SS376TE-17
D306 8-719-970-83 DIODE HSS82-TJ
D308 8-719-066-10 DIODE 1PS181-115
D311 8-719-062-51 DIODE 1PS226-115
FERRITE BEAD
FB002 1-216-295-00 SHORT CHIP 1/8W
FB003 1-412-911-11 FERRITE 0µH
FB004 1-412-911-11 FERRITE 0µH
FB005 1-412-911-11 FERRITE 0µH
FB006 1-216-295-00 SHORT CHIP 1/8W
FB007 1-216-295-00 SHORT CHIP 1/8W
FB008 1-216-295-00 SHORT CHIP 1/8W
FB009 1-414-231-22 FERRITE 0µH
FB102 1-469-965-21 INDUCTOR 0µH
FB103 1-469-965-21 INDUCTOR 0µH
FB104 1-412-911-11 FERRITE 0µH
FB110 1-412-911-11 FERRITE 0µH
FB202 1-469-965-21 INDUCTOR 0µH
FB203 1-469-965-21 INDUCTOR 0µH
FB210 1-412-911-11 FERRITE 0µH
FB302 1-469-965-21 INDUCTOR 0µH
FB303 1-469-965-21 INDUCTOR 0µH
FB310 1-412-911-11 FERRITE 0µH
IC
IC001 6-700-496-01 IC M61314SP
IC002 8-759-824-97 IC LM2412T/JL860089
IC003 8-759-681-38 IC CXD9548MTR
IC004 8-749-019-91 IC H8D3104
IC005 8-759-058-60 IC TC7SU04FU(TE85R)
IC006 8-759-491-32 IC TC74VHCT04AF(EL)
IC007 8-759-640-39 IC BR24C02F-WE2
IC008 8-759-680-71 IC MM1470AD
IC009 8-759-640-39 IC BR24C02F-WE2
IC011 8-759-592-79 IC BA00AST-V5
JACK
!
J001 1-451-524-11 SOCKET, CRT
CHIP CONDUCTOR
JR001 1-216-296-00 SHORT CHIP 1/4W
JR002 1-216-296-00 SHORT CHIP 1/4W
JR005 1-216-296-00 SHORT CHIP 1/4W
JR007 1-216-295-00 SHORT CHIP 1/8W
JR008 1-216-296-00 SHORT CHIP 1/4W
