Sony CPD-E530 - Page 48

REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
NOTE: The components identied by shading
and
!
mark are critical for safety. Replace only
with part number specied.
A component identied by this
symbol indicates that it
has been carefully factory-selected to satisfy regulations
regarding X-ray radiation. Should replacement be required,
replace only with the value originally used.
R942 1-218-776-11 METAL CHIP 1M 0.50% 1/10W
R943 1-216-699-11 METAL CHIP 100K 0.50% 1/10W
R944 1-216-049-00 METAL CHIP 1K 5% 1/10W
R945 1-216-025-00 METAL CHIP 100 5% 1/10W
R946 1-216-675-11 METAL CHIP 10K 0.50% 1/10W
R950 1-216-049-00 METAL CHIP 1K 5% 1/10W
R951 1-216-699-11 METAL CHIP 100K 0.50% 1/10W
R952 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R953 1-216-129-00 METAL CHIP 2.2M 5% 1/10W
R954 1-218-179-11 METAL CHIP 10M 5% 1/10W
R955 1-218-179-11 METAL CHIP 10M 5% 1/10W
VARIABLE RESISTOR
RV901 1-241-767-21 RES, ADJ, CERMET 100K
RELAY
!
RY602 1-755-318-11 RELAY, POWER
!
RY603 1-755-067-21 RELAY
SWITCH
S501 1-692-465-11 SWITCH, SLIDE
!
S601 1-771-727-11 SWITCH, AC POWER PUSH
SPARK GAP
!
SG601 1-533-982-21 GAP, SPARK
SG901 1-517-499-21 GAP, SPARK
SG902 1-519-422-11 GAP, SPARK
SG903 1-519-422-11 GAP, SPARK
TRANSFORMER
T501 1-435-188-11 TRANSFORMER, FERRITE (HDT)
T503 1-435-140-21 TRANSFORMER, FERRITE (LCT)
T504 1-433-946-21 TRANSFORMER, FERRITE (HST)
!
T601 1-429-180-11 TRANSFORMER, LINE FILTER
!
T620 1-435-748-31 TRANSFORMER, CONVERTER (PIT)
!
T630 1-435-751-31 TRANSFORMER, CONVERTER (SRT)
T701 1-435-142-31 TRANSFORMER, FERRITE (DFT)
!
T901 1-453-382-11 FBT ASSY/NX-4702/KQE4
!
T902 1-419-345-31 INDUCTOR 500µH
THERMISTOR
TH401 1-807-925-11 THERMISTOR
TH601 1-809-260-11 THERMISTOR, POWER
THP602 1-809-827-11 THERMISTOR, POSITIVE
VARISTOR
VDR601 1-803-918-11 VARISTOR (TNR14V621K660)
VDR602 1-810-622-11 VARISTOR
DA
* A-1333-007-A DA BOARD, MOUNTED
CAPACITOR
C1101 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1102 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1103 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1104 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1105 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1108 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1109 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1110 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1111 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1112 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1113 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1114 1-163-017-00 CERAMIC CHIP 0.0047µF 10% 50V
C1115 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1116 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1117 1-163-019-00 CERAMIC CHIP 0.0068µF 10% 50V
C1118 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1119 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1120 1-163-251-11 CERAMIC CHIP 100pF 5% 50V
C1121 1-163-019-00 CERAMIC CHIP 0.0068µF 10% 50V
C1122 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1123 1-163-809-11 CERAMIC CHIP 0.047µF 10% 25V
C1124 1-163-251-11 CERAMIC CHIP 100pF 5% 50V
C1125 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1126 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1127 1-125-838-11 CERAMIC CHIP 2.2µF 10% 6.3V
C1128 1-126-246-11 ELECT CHIP 220µF 20% 4V
C1129 1-163-007-11 CERAMIC CHIP 680pF 10% 50V
C1130 1-164-492-11 CERAMIC CHIP 0.15µF 10% 16V
C1131 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1132 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1133 1-126-246-11 ELECT CHIP 220µF 20% 4V
C1137 1-126-205-11 ELECT CHIP 47µF 20% 6.3V
C1138 1-163-251-11 CERAMIC CHIP 100pF 5% 50V
DA
D
— 48 —
CPD-E530
