Sony CPD-E530 - Page 49

REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
C1139 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1140 1-163-251-11 CERAMIC CHIP 100pF 5% 50V
DIODE
D1104 8-719-027-76 DIODE 1SS357-TPH3
D1105 8-719-067-40 DIODE STZ6.8N-T146
D1106 8-719-067-40 DIODE STZ6.8N-T146
D1107 8-719-067-40 DIODE STZ6.8N-T146
FERRITE BEAD
FB1101 1-543-963-22 FERRITE 0µH
IC
IC1101 8-759-697-78 IC CXD9563Q
IC1102 8-759-701-01 IC NJM2904M
RESISTOR
R1101 1-216-025-00 METAL CHIP 100 5% 1/10W
R1102 1-216-057-00 METAL CHIP 2.2K 5% 1/10W
R1103 1-216-025-00 METAL CHIP 100 5% 1/10W
R1106 1-216-691-11 METAL CHIP 47K 0.50% 1/10W
R1108 1-216-669-11 METAL CHIP 5.6K 0.50% 1/10W
R1109 1-216-669-11 METAL CHIP 5.6K 0.50% 1/10W
R1110 1-216-675-91 METAL CHIP 10K 0.50% 1/10W
R1111 1-216-673-11 METAL CHIP 8.2K 0.50% 1/10W
R1112 1-216-675-11 METAL CHIP 10K 0.50% 1/10W
R1113 1-216-665-11 METAL CHIP 3.9K 0.50% 1/10W
R1114 1-216-049-00 METAL CHIP 1K 5% 1/10W
R1115 1-216-691-11 METAL CHIP 47K 0.50% 1/10W
R1116 1-216-655-11 METAL CHIP 1.5K 0.50% 1/10W
R1118 1-216-675-11 METAL CHIP 10K 0.50% 1/10W
R1119 1-216-049-00 METAL CHIP 1K 5% 1/10W
R1122 1-216-659-11 METAL CHIP 2.2K 0.50% 1/10W
R1123 1-216-656-11 METAL CHIP 1.6K 0.50% 1/10W
R1124 1-216-643-11 METAL CHIP 470 0.50% 1/10W
R1125 1-216-659-11 METAL CHIP 2.2K 0.50% 1/10W
R1126 1-216-642-11 METAL CHIP 430 0.50% 1/10W
R1127 1-216-675-11 METAL CHIP 10K 0.50% 1/10W
R1128 1-218-760-11 METAL CHIP 220K 0.50% 1/10W
R1129 1-216-683-11 METAL CHIP 22K 0.50% 1/10W
R1131 1-216-025-00 METAL CHIP 100 5% 1/10W
R1132 1-216-025-00 METAL CHIP 100 5% 1/10W
R1133 1-218-776-11 METAL CHIP 1M 0.50% 1/10W
R1134 1-216-663-11 METAL CHIP 3.3K 0.50% 1/10W
R1135 1-218-776-11 METAL CHIP 1M 0.50% 1/10W
R1136 1-216-049-00 METAL CHIP 1K 5% 1/10W
R1137 1-218-758-11 METAL CHIP 180K 0.50% 1/10W
R1139 1-216-691-11 METAL CHIP 47K 0.50% 1/10W
R1141 1-216-025-00 METAL CHIP 100 5% 1/10W
R1142 1-216-295-91 SHORT CHIP
RESISTOR BRIDGE
RB1101 1-233-576-11 RES, CHIP NETWORK 100
RB1102 1-233-412-11 RES, CHIP NETWORK 1.0K (3216)
RB1103 1-233-412-11 RES, CHIP NETWORK 1.0K (3216)
RB1104 1-233-576-11 RES, CHIP NETWORK 100
RB1105 1-233-576-11 RES, CHIP NETWORK 100
RB1106 1-233-412-11 RES, CHIP NETWORK 1.0K (3216)
N
* A-1391-095-A N BOARD, MOUNTED
CAPACITOR
C1001 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1002 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1004 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1005 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1014 1-126-205-11 ELECT CHIP 47µF 20% 6.3V
C1015 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1016 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1017 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1018 1-163-220-11 CERAMIC CHIP 3pF 0.25pF 50V
C1019 1-163-235-11 CERAMIC CHIP 22pF 5% 50V
C1020 1-126-206-11 ELECT CHIP 100µF 20% 6.3V
C1021 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1022 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1023 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1027 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1028 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1029 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1030 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
CONNECTOR
* CN1003 1-564-521-11 PLUG, CONNECTOR 6P
DA
N
— 49 —
CPD-E530
