REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
DIODE
D1001 8-719-404-50 DIODE MA111-TX
FERRITE BEAD
FB1001 1-543-963-22 FERRITE 0µH
FB1005 1-216-295-00 SHORT CHIP 1/8W
IC
IC1001 6-800-272-01 IC TMP91CW18F-2C36(Z)
IC1002 8-759-420-77 IC PST574CMT-T1
IC1003 8-759-641-86 IC BR24C16F-E2
TRANSISTOR
Q1001 8-729-029-06 TRANSISTOR DTC124EUA-T106
RESISTOR
R1001 1-216-125-00 METAL CHIP 1.5M 5% 1/10W
R1003 1-216-025-00 METAL CHIP 100 5% 1/10W
R1004 1-216-667-11 METAL CHIP 4.7K 0.50% 1/10W
R1005 1-216-667-11 METAL CHIP 4.7K 0.50% 1/10W
R1006 1-216-667-11 METAL CHIP 4.7K 0.50% 1/10W
R1008 1-216-025-00 METAL CHIP 100 5% 1/10W
R1009 1-216-025-00 METAL CHIP 100 5% 1/10W
R1010 1-216-049-00 METAL CHIP 1K 5% 1/10W
R1011 1-216-667-11 METAL CHIP 4.7K 0.50% 1/10W
R1012 1-216-667-11 METAL CHIP 4.7K 0.50% 1/10W
R1014 1-216-667-11 METAL CHIP 4.7K 0.50% 1/10W
R1015 1-216-667-11 METAL CHIP 4.7K 0.50% 1/10W
R1016 1-216-025-00 METAL CHIP 100 5% 1/10W
R1017 1-216-049-00 METAL CHIP 1K 5% 1/10W
R1018 1-216-017-00 METAL CHIP 47 5% 1/10W
R1019 1-216-017-00 METAL CHIP 47 5% 1/10W
R1020 1-216-017-00 METAL CHIP 47 5% 1/10W
R1021 1-216-017-00 METAL CHIP 47 5% 1/10W
R1022 1-216-667-11 METAL CHIP 4.7K 0.50% 1/10W
R1023 1-216-667-11 METAL CHIP 4.7K 0.50% 1/10W
R1040 1-216-025-00 METAL CHIP 100 5% 1/10W
R1041 1-216-667-11 METAL CHIP 4.7K 0.50% 1/10W
R1042 1-216-675-11 METAL CHIP 10K 0.50% 1/10W
R1043 1-218-776-11 METAL CHIP 1M 0.50% 1/10W
R1044 1-218-776-11 METAL CHIP 1M 0.50% 1/10W
RESISTOR BRIDGE
RB1001 1-233-576-11 RES, CHIP NETWORK 100
RB1002 1-233-576-11 RES, CHIP NETWORK 100
RB1003 1-233-576-11 RES, CHIP NETWORK 100
RB1004 1-233-576-11 RES, CHIP NETWORK 100
RB1005 1-233-576-11 RES, CHIP NETWORK 100
RB1006 1-233-576-11 RES, CHIP NETWORK 100
RB1007 1-233-576-11 RES, CHIP NETWORK 100
RB1009 1-233-576-11 RES, CHIP NETWORK 100
CRYSTAL
X1001 1-795-044-21 VIBRATOR, CRYSTAL
L2
* A-1391-119-A L2 BOARD, MOUNTED
CAPACITOR
C1600 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1604 1-163-003-11 CERAMIC CHIP 330pF 10% 50V
C1605 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1606 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1607 1-163-003-11 CERAMIC CHIP 330pF 10% 50V
C1608 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1611 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1613 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1614 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1617 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1618 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1619 1-163-038-91 CERAMIC CHIP 0.1µF 25V
C1621 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1622 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1623 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
C1627 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
C1628 1-126-947-11 ELECT 47µF 20% 35V
C1629 1-163-021-91 CERAMIC CHIP 0.01µF 10% 50V
C1632 1-126-947-11 ELECT 47µF 20% 35V
C1633 1-126-791-11 ELECT 10µF 20% 35V
C1637 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1638 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C1639 1-126-947-11 ELECT 47µF 20% 35V
C1640 1-126-947-11 ELECT 47µF 20% 35V
N
L2
— 50 —
CPD-E530
