REF. NO. PART NO. DESCRIPTION VALUES
REF. NO. PART NO. DESCRIPTION VALUES
English
2003AJ74WEB-1
Printed in USA
© 2003.1
CONNECTOR
CN1600 1-564-505-11 PLUG, CONNECTOR 2P
* CN1601 1-564-507-11 PLUG, CONNECTOR 4P
* CN1602 1-564-511-11 PLUG, CONNECTOR 8P
FERRITE BEAD
FB1600 1-412-911-11 FERRITE 0µH
FB1601 1-412-911-11 FERRITE 0µH
FB1602 1-412-911-11 FERRITE 0µH
FB1603 1-412-911-11 FERRITE 0µH
FB1604 1-412-911-11 FERRITE 0µH
IC
IC1600 8-759-822-38 IC LA6510
IC1601 8-759-822-38 IC LA6510
IC1602 8-759-426-18 IC MB88141pF-ER
IC1603 8-759-803-42 IC LA6500-FA
IC1604 8-759-822-38 IC LA6510
IC1605 8-759-711-59 IC NJM78L05UA-TE1
RESISTOR
R1600 1-216-675-11 METAL CHIP 10K 0.50% 1/10W
R1601 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R1603 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R1604 1-216-675-11 METAL CHIP 10K 0.50% 1/10W
R1605 1-215-859-00 METAL OXIDE 22 5% 1W
R1607 1-215-859-00 METAL OXIDE 22 5% 1W
R1608 1-216-673-11 METAL CHIP 8.2K 0.50% 1/10W
R1609 1-216-667-11 METAL CHIP 4.7K 0.50% 1/10W
R1610 1-216-673-11 METAL CHIP 8.2K 0.50% 1/10W
R1611 1-215-859-00 METAL OXIDE 22 5% 1W
R1613 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R1617 1-216-667-11 METAL CHIP 4.7K 0.50% 1/10W
R1621 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R1624 1-216-675-11 METAL CHIP 10K 0.50% 1/10W
R1625 1-216-675-11 METAL CHIP 10K 0.50% 1/10W
R1626 1-215-859-00 METAL OXIDE 22 5% 1W
R1628 1-216-675-11 METAL CHIP 10K 0.50% 1/10W
R1629 1-216-675-11 METAL CHIP 10K 0.50% 1/10W
R1630 1-215-859-00 METAL OXIDE 22 5% 1W
R1631 1-216-675-11 METAL CHIP 10K 0.50% 1/10W
R1634 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R1635 1-216-679-11 METAL CHIP 15K 0.50% 1/10W
R1636 1-215-859-00 METAL OXIDE 22 5% 1W
R1640 1-216-667-11 METAL CHIP 4.7K 0.50% 1/10W
R1641 1-216-681-11 METAL CHIP 18K 0.50% 1/10W
R1643 1-216-308-00 METAL CHIP 4.7 5% 1/10W
R1644 1-216-053-00 METAL CHIP 1.5K 5% 1/10W
R1647 1-216-675-11 METAL CHIP 10K 0.50% 1/10W
R1648 1-216-675-11 METAL CHIP 10K 0.50% 1/10W
R1649 1-215-859-00 METAL OXIDE 22 5% 1W
R1650 1-249-382-11 CARBON 1.2 5% 1/4W
R1651 1-249-382-11 CARBON 1.2 5% 1/4W
R1652 1-249-382-11 CARBON 1.2 5% 1/4W
R1653 1-249-382-11 CARBON 1.2 5% 1/4W
R1654 1-216-025-00 METAL CHIP 100 5% 1/10W
R1655 1-216-025-00 METAL CHIP 100 5% 1/10W
L2
