Pin No. Pin Name I/O Description
46 IGEN I
Stabilized current input for operational amplifiers
47 AVDD0 —
Power supply terminal (+3.3V) (analog system)
48 ASYO O
EFM full-swing output terminal
49 ASYI I
Asymmetry comparator voltage input terminal
50 RFAC I
EFM signal input from the RF amplifier
51 AVSS1 —
Ground terminal (analog system)
52 CLTV I
Internal VCO control voltage input terminal
53 FILO O
Filter output for master PLL
54 FILI I
Filter input for master PLL
55 PCO O
Charge pump output for master PLL
56 AVDD1 —
Power supply terminal (+3.3V) (analog system)
57 BIAS I
Asymmetry circuit constant current input terminal
58 VCTL I
VCO control voltage input terminal for the wideband EFM PLL Not used
59 V16M O
VCO oscillation output terminal for the wideband EFM PLL Not used
60 VPCO O
Charge pump output terminal for the wideband EFM PLL Not used
61 DVDD2 —
Power supply terminal (+3.3V) (digital system)
62 ASYE I
Asymmetry circuit on/off control signal input terminal “L”: off, “H”: on Not used
63 MD2 I
Digital out on/off control signal input terminal
“L”: digital out off, “H”: digital out on Fixed at “H” in this set
64 DOUT O
Digital audio signal output terminal
65 LRCK O
L/R sampling clock signal (44.1 kHz) output to the MP3 decoder
66 PCMD O
Serial data output to the MP3 decoder
67 BCLK O
Bit clock signal (2.8224 MHz) output to the MP3 decoder
68 EMPH O
“L” is output when playback disc is emphasis off
“H” is output when playback disc is emphasis on Not used
69 XTSL I
Input terminal for the system clock frequency setting
“L”: 16.9344 MHz, “H”: 33.8688MHz Fixed at “H” in this set
70 DVSS2 —
Ground terminal (digital system)
71 XTAI I
System clock input terminal (33.8688 MHz)
72 XTAO O
System clock output terminal (33.8688 MHz) Not used
73 SOUT O
Serial data output terminal Not used
74 SOCK O
Serial data reading clock signal output terminal Not used
75 XOLT O
Serial data latch pulse signal output terminal Not used
76 SQSO O
Subcode Q data output to the system controller
77 SQCK I
Subcode Q data reading clock signal input from the system controller
78 SCSY I
Input terminal for resynchronism of guard subcode sync (S0+S1) Not used
79 SBSO O
Subcode serial data output terminal Not used
80 EXCK I
Subcode serial data reading clock signal input terminal Not used
