CX-LDB10/LDB20
CX-LDB10/LDB20
7-13. PRINTED WIRING BOARD — POWER BOARD —
• See page 15 for Circuit Boards Location. :Uses unleaded solder.
RY901
W903
R954
R955
MX
MX
VOLTAGE
SELECTOR
POWER (1) BOARD (SIDE B)
1-865-485-
1-865-739-
POWER(2) BOARD (SIDE B)
T902
CN901
MAIN
BOARD
CN001
(Page 21)
E
AC IN
CN903
T901
W901
1-865-739-
POWER(2) BOARD (SIDE A)
S901
POWER (1) BOARD (SIDE A)
1-865-485-
(CHASSIS)
12
A
B
C
D
E
34567 9
8
10 12
11
F
14
13
• Semiconductor
Location
Ref. No. Location
D901 F-2
D902 F-2
D903 E-2
D904 E-2
D905 E-4
D907 D-2
D908 D-2
D909 D-2
D910 C-2
D911 F-3
D912 C-4
D914 C-4
D916 C-4
D918 B-7
D921 C-4
D922 C-4
D925 D-5
D926 D-5
Q901 C-5
Q902 C-5
Q903 C-5
Q904 C-5
