42
CX-LDB10/LDB20
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C410 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C411 1-124-584-00 ELECT 100uF 20% 10V
C412 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C413 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C414 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C415 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C416 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C417 1-104-655-91 ELECT 470uF 20% 6.3V
C418 1-124-589-11 ELECT 47uF 20% 16V
C419 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C420 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C421 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C422 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C423 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C424 1-124-234-00 ELECT 22uF 20% 16V
C425 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C426 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C427 1-124-234-00 ELECT 22uF 20% 16V
C428 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C430 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C431 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C432 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C433 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C434 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C435 1-216-864-11 SHORT CHIP 0
C436 1-216-864-11 SHORT CHIP 0
C439 1-124-261-00 ELECT 10uF 20% 25V
C441 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C442 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C443 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C444 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C445 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
CN401 1-784-778-11 CONNECTOR, FFC 17P
CN402 1-784-776-11 CONNECTOR, FFC 15P (AEP)
CN403 1-784-784-11 CONNECTOR, FFC 23P
CN404 1-568-826-11 CONNECTOR, FFC 7P
< DIODE >
D403 8-719-988-61 DIODE 1SS355TE-17
D404 8-719-988-61 DIODE 1SS355TE-17
D405 8-719-988-61 DIODE 1SS355TE-17
D406 8-719-988-61 DIODE 1SS355TE-17
D408 8-719-000-07 DIODE MC2836
D409 8-719-069-54 DIODE UDZSTE-175.1B
D410 8-719-059-98 DIODE SLR-342VC3F (LDB20)
D411 8-719-059-98 DIODE SLR-342VC3F (LDB20)
D412 8-719-059-98 DIODE SLR-342VC3F (LDB20)
D413 8-719-059-98 DIODE SLR-342VC3F (LDB20)
D414 8-719-059-98 DIODE SLR-342VC3F (LDB20)
D415 8-719-059-98 DIODE SLR-342VC3F (LDB20)
D416 8-719-059-98 DIODE SLR-342VC3F
D418 8-719-988-61 DIODE 1SS355TE-17
D419 8-719-988-61 DIODE 1SS355TE-17
D420 8-719-000-07 DIODE MC2836
< FILTER >
FL401 1-519-819-11 INDICATOR TUBE, FLUORESCENT
< IC >
IC401 6-805-229-01 IC M30392MCP-A08FPU0
IC402 6-600-349-31 IC NJL24H400A ( )
IC403 6-701-680-01 IC PST3629NR
< SHORT >
JC401 1-216-864-11 SHORT CHIP 0
JC402 1-216-864-11 SHORT CHIP 0
JC409 1-216-864-11 SHORT CHIP 0
JC411 1-216-296-11 SHORT CHIP 0
JC412 1-216-296-11 SHORT CHIP 0
JC413 1-216-296-11 SHORT CHIP 0
JC414 1-216-864-11 SHORT CHIP 0 (MX)
JC415 1-216-864-11 SHORT CHIP 0 (MX)
JC416 1-216-296-11 SHORT CHIP 0 (MX)
JC417 1-216-296-11 SHORT CHIP 0 (MX)
JC418 1-216-864-11 SHORT CHIP 0 (MX)
JC419 1-216-296-11 SHORT CHIP 0 (MX)
JC420 1-216-296-11 SHORT CHIP 0 (MX)
JC421 1-216-296-11 SHORT CHIP 0 (MX)
JC422 1-216-296-11 SHORT CHIP 0 (MX)
JC423 1-216-296-11 SHORT CHIP 0 (MX)
JC424 1-216-296-11 SHORT CHIP 0 (MX)
JC425 1-216-864-11 SHORT CHIP 0 (MX)
< COIL >
L401 1-216-296-11 SHORT CHIP 0
L402 1-216-296-11 SHORT CHIP 0
L403 1-216-296-11 SHORT CHIP 0
< TRANSISTOR >
Q401 8-729-602-21 TRANSISTOR 2SC4154-F
Q402 8-729-037-13 TRANSISTOR KTA1271Y
Q403 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q404 8-729-040-76 TRANSISTOR KTA1273-Y-AT
Q405 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q407 8-729-027-43 TRANSISTOR DTC114EKA-T146 (LDB20)
Q408 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q409 8-729-602-21 TRANSISTOR 2SC4154-F
< RESISTOR >
R401 1-216-809-11 METAL CHIP 100 5% 1/10W
R402 1-216-809-11 METAL CHIP 100 5% 1/10W
R403 1-216-809-11 METAL CHIP 100 5% 1/10W
R404 1-216-809-11 METAL CHIP 100 5% 1/10W
R405 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R406 1-216-821-11 METAL CHIP 1K 5% 1/10W
R407 1-219-570-11 METAL CHIP 10M 5% 1/10W
R408 1-216-849-11 METAL CHIP 220K 5% 1/10W
R410 1-216-864-11 SHORT CHIP 0
R412 1-216-849-11 METAL CHIP 220K 5% 1/10W
R414 1-216-841-11 METAL CHIP 47K 5% 1/10W
R418 1-216-809-11 METAL CHIP 100 5% 1/10W
CONTROL
