CX-LDB10/LDB20
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R613 1-216-817-11 METAL CHIP 470 5% 1/10W
(EXCEPT MX)
R613 1-216-821-11 METAL CHIP 1K 5% 1/10W
(MX)
R614 1-216-817-11 METAL CHIP 470 5% 1/10W
(EXCEPT MX)
R614 1-216-821-11 METAL CHIP 1K 5% 1/10W
(MX)
R615 1-216-817-11 METAL CHIP 470 5% 1/10W
(EXCEPT MX)
R615 1-216-821-11 METAL CHIP 1K 5% 1/10W
(MX)
R616 1-216-813-11 METAL CHIP 220 5% 1/10W
(EXCEPT MX)
R616 1-216-821-11 METAL CHIP 1K 5% 1/10W
(MX)
R617 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R618 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
< RELAY >
RY351 1-755-170-11 RELAY (LDB20)
< TRANSFORMER >
T251 1-433-372-31 TRANSFORMER, BIAS OSCILLATION
< THERMISTOR >
TH351 1-805-217-21 THERMISTOR (1012)
************************************************************
A-1095-599-A POWER (1) BOARD, COMPLETE
(LDB20: AEP, RU)
A-1095-628-A POWER (1) BOARD, COMPLETE
(LDB10: KR, AR, AEP, RU, AUS)
A-1108-995-A POWER (1) BOARD, COMPLETE (LDB20: E51)
A-1109-028-A POWER (1) BOARD, COMPLETE
(LDB10: SP, MY, E51)
A-1109-035-A POWER (1) BOARD, COMPLETE (MX)
**************************
< CONNECTOR >
* CN901 1-695-044-11 PIN, CONNECTOR (3.96mm PITCH) 2P
< DIODE >
D918 8-719-988-61 DIODE 1SS355TE-17
< LINE FILTER >
0LF901 1-402-663-11 TRANSFORMER, LINE FILTER (LFT)
< RELAY >
0RY901 1-755-276-11 RELAY, POWER
< TRANSFORMER >
0T901 1-443-410-11 TRANSFORMER, POWER
(KR, AR, AEP, RU, AUS)
0T901 1-443-412-11 TRANSFORMER, POWER (MX, SP, MY, E51)
************************************************************
A-1095-601-A POWER (2) BOARD, COMPLETE (LDB20)
A-1095-629-A POWER (2) BOARD, COMPLETE (LDB10)
**************************
< CAPACITOR >
C901 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C903 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C905 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C906 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C908 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C909 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C912 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C913 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C916 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C917 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C919 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C921 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C923 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C925 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
C927 1-115-339-11 CERAMIC CHIP 0.1uF 10% 50V
< CONNECTOR >
* CN903 1-564-706-11 PIN, CONNECTOR (SMALL TYPE) 4P
< DIODE >
D901 8-719-046-47 DIODE 1N5401TM
D902 8-719-046-47 DIODE 1N5401TM
D903 8-719-046-47 DIODE 1N5401TM
D904 8-719-046-47 DIODE 1N5401TM
D905 8-719-000-08 DIODE MC2838
D907 8-719-063-79 DIODE 1N4002B
D908 8-719-063-79 DIODE 1N4002B
D909 8-719-063-79 DIODE 1N4002B
D910 8-719-063-79 DIODE 1N4002B
D911 6-500-522-01 DIODE 10EDB40-TA1B2
D912 8-719-000-08 DIODE MC2838
D914 8-719-000-08 DIODE MC2838
D916 8-719-000-07 DIODE MC2836
D921 8-719-000-08 DIODE MC2838
D922 8-719-000-07 DIODE MC2836
D925 8-719-988-61 DIODE 1SS355TE-17
D926 8-719-988-61 DIODE 1SS355TE-17
< TRANSISTOR >
Q901 8-729-027-31 TRANSISTOR DTA124EKA-T146
Q902 8-729-027-31 TRANSISTOR DTA124EKA-T146
Q903 8-729-027-43 TRANSISTOR DTC114EKA-T146
Q904 8-729-027-31 TRANSISTOR DTA124EKA-T146
< RESISTOR >
R901 1-216-845-11 METAL CHIP 100K 5% 1/10W
R902 1-216-845-11 METAL CHIP 100K 5% 1/10W
R903 1-216-849-11 METAL CHIP 220K 5% 1/10W
R904 1-216-849-11 METAL CHIP 220K 5% 1/10W
R915 1-216-864-11 SHORT CHIP 0
R916 1-216-841-11 METAL CHIP 47K 5% 1/10W
R918 1-216-833-11 METAL CHIP 10K 5% 1/10W
MAIN POWER (1) POWER (2)
