Sony DCR-DVD110E - Page 190

6-58
DCR-DVD110E/DVD115E/DVD310E/DVD410E/DVD610/
DVD610E/DVD710/DVD710E/DVD810/DVD810E_ADJ
Purpose Trouble Symptom Cause Repair
Faulty Flash IC Replace the VC board
Faulty DSP IC Replace the VC board
Purpose Trouble Symptom Cause Repair
Adjust the servo with
DVD-RW
The disc is dirty or has
scratches on it
Check disc
Faulty OP Replace the MD block
Faulty DSP IC Replace the VC board
Faulty RF IC Replace the VC board
DVD-RW Self Jitter
Purpose Trouble Symptom Cause Repair
The disc is dirty or has
scratches on it
Check disc
Faulty OP Replace the MD block
Faulty DSP IC Replace the VC board
Faulty RF IC Replace the VC board
DVD-R Self Jitter
Purpose Trouble Symptom Cause Repair
The disc is dirty or has
scratches on it
Check disc
Faulty OP Replace the MD block
Faulty DSP IC Replace the VC board
Faulty RF IC Replace the VC board
DVD+RDL Self Jitter
Purpose Trouble Symptom Cause Repair
Adjust the servo with
DVD+RDL
The disc is dirty or has
scratches on it
Check disc
Faulty OP Replace the MD block
Faulty DSP IC Replace the VC board
Faulty RF IC Replace the VC board
Data Dump
Purpose Trouble Symptom Cause Repair
Faulty DSP IC Replace the VC board
Faulty RF IC Replace the VC board
The adjustment value is
dumped
Servo Parameter Initialize
Adjust the recording with
DVD+RDL
Check the self recording with
DVD+RDL
Initialization of servo-related
adjustment data
DVD-RW Reference Disc Adjustment
Adjust the recording with
DVD-RW
Check the self recording with
DVD-RW
Adjust the servo with DVD-R
Adjust the recording with
DVD-R
Check the self recording with
DVD-R
2-6-4. Servo Adjust
