Sony DCR-DVD110E - CD-731; CK-191; CK-192

5-12
Ref. No. Part No. Description Ref. No. Part No. Description
DCR-DVD110E/DVD115E/DVD310E/DVD410E/DVD610/
DVD610E/DVD710/DVD710E/DVD810/DVD810E_L2
A-1439-626-A CD-731 BOARD, COMPLETE
(DVD110E/DVD115E/DVD610/DVD610E)
**********************
(IC7101 is not included in CD-731 complete
board.)
< CAPACITOR >
C7101 1-124-779-00 ELECT CHIP 10uF 20% 16V
C7103 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C7104 1-124-779-00 ELECT CHIP 10uF 20% 16V
C7105 1-164-854-11 CERAMIC CHIP 15PF 5% 50V
C7108 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
* CN7101 1-816-646-51 FFC/CONNECTOR, FPC (LIF) 16P
< IC >
IC7101 8-753-288-68 ICX650NKF-H (CCD IMAGER) (DVD610)
(Note 1)
IC7101 8-753-289-10 ICX651NKF-H (CCD IMAGER)
(DVD110E/DVD115E/DVD610E) (Note 1)
< COIL >
L7101 1-400-588-11 INDUCTOR 10uH
< TRANSISTOR >
* Q7101 6-551-873-01 TRANSISTOR 2SC3931G0LS0
< RESISTOR >
R7101 1-218-959-11 RES-CHIP 3.3K 5% 1/16W
A-1439-630-A CK-191 BOARD, COMPLETE
(DVD110E/DVD115E/DVD610/DVD610E)
**********************
(BT901 (lithium battery) is not included in
CK-191 complete board.)
< BATTERY HOLDER >
0* BH5801 1-756-615-51 HOLDER, BATTERY (Note 2)
< BATTERY >
0BT901 1-756-134-12 BATTERY, STORAGE, LITHIUM ION (Note 2)
< CONNECTOR >
* CN5801 1-816-643-51 FFC/CONNECTOR, FPC (LIF) 10P
< DIODE >
D5801 8-719-077-09 DIODE CL-196HR-CD-T (MS ACCESS)
< RESISTOR >
R5802 1-218-945-11 RES-CHIP 220 5% 1/16W
< SWITCH >
S5801 1-771-844-21 SWITCH, TACTILE (SMD) (RESET)
S5802 1-771-844-21 SWITCH, TACTILE (SMD) (DISP/BATT INFO)
S5806 1-771-844-21 SWITCH, TACTILE (SMD) (N)
A-1439-643-A CK-192 BOARD, COMPLETE
(DVD310E/DVD710/DVD710E)
A-1439-644-A CK-192 BOARD, COMPLETE
(DVD410E/DVD810/DVD810E)
**********************
(BT901 (lithium battery) is not included in
CK-192 complete board.)
< BATTERY HOLDER >
0* BH5801 1-756-615-51 HOLDER, BATTERY (Note 2)
< BATTERY >
0 BT901 1-756-134-12 BATTERY, STORAGE, LITHIUM ION (Note 2)
< CONNECTOR >
* CN5801 1-816-643-51 FFC/CONNECTOR, FPC (LIF) 10P
< DIODE >
D5801 8-719-077-09 DIODE CL-196HR-CD-T (MS ACCESS)
< RESISTOR >
R5801 1-218-954-11 RES-CHIP 1.2K 5% 1/16W
(DVD410E/DVD810/DVD810E)
R5802 1-218-945-11 RES-CHIP 220 5% 1/16W
< SWITCH >
S5801 1-771-844-21 SWITCH, TACTILE (SMD) (RESET)
S5802 1-771-844-21 SWITCH, TACTILE (SMD) (DISP/BATT INFO)
S5803 1-771-844-21 SWITCH, TACTILE (SMD) (DUBBING)
(DVD410E/DVD810/DVD810E)
S5806 1-771-844-21 SWITCH, TACTILE (SMD) (N)
CD-731 CK-191 CK-192
Note 1: イメージャの交換時は4- 3ページのイメージャ
交換時の注意を必ずお読みください。
Note 1: Be sure to read “Precautions for Replacement of
Imager” on page 4-2 when changing the imager.
注意
電池の交換は，正しく行わないと破裂する恐れがあり
ます。電池を交換する場合には必ず同じ型名の電池
又は同等品と交換してください。
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
Note 2: CK-191基板およびCK-192基板のリチウム電池（BT901）
を交換する場合はバッテリホルダ（BH5801）も同時に
新品に交換して下さい。（一度使用したバッテリホルダ
は再使用できません。）
部品取り付けの際は，先にバッテリホルダを取り付けて
からリチウム電池を装着してください。
Note 2: Replace the battery holder (BH5801) together when re-
placing the lithium battery (BT901) on the CK-191 board
and CK-192 board. (The battery holder removed once
cannot be used again.)
When mounting these parts, mount new battery holder
first and attach new lithium battery next.
• Refer to page 5-1 for mark 0.
