Sony DCR-DVD110E - ELECTRICAL PARTS LIST; BL-021; BL-022; CD-672

5-11
Ref. No. Part No. Description Ref. No. Part No. Description
5-2. ELECTRICAL PARTS LIST
DCR-DVD110E/DVD115E/DVD310E/DVD410E/DVD610/
DVD610E/DVD710/DVD710E/DVD810/DVD810E_L2
A-1439-629-A BL-021 BOARD, COMPLETE
(DVD110E/DVD115E/DVD610/DVD610E)
**********************
< CAPACITOR >
C5701 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5702 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
< CONNECTOR >
* CN5701 1-779-333-51 CONNECTOR, FFC/FPC 18P
* CN5702 1-817-698-81 CONNECTOR, FPC (ZIF) 21P
< DIODE >
D5701 8-719-074-67 DIODE EDZ-TE61-5.6B
* D5702 6-501-591-01 DIODE NESW007AT-T099 (BACKLIGHT)
< RESISTOR >
R5702 1-218-989-11 RES-CHIP 1M 5% 1/16W
A-1439-642-A BL-022 BOARD, COMPLETE
(DVD310E/DVD410E/DVD710/DVD710E/
DVD810/DVD810E)
**********************
< CAPACITOR >
C5701 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5702 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
< CONNECTOR >
* CN5701 1-779-333-51 CONNECTOR, FFC/FPC 18P
* CN5702 1-817-698-81 CONNECTOR, FPC (ZIF) 21P
< DIODE >
* D5701 6-501-591-01 DIODE NESW007AT-T099 (BACKLIGHT)
D5702 8-719-074-67 DIODE EDZ-TE61-5.6B
A-1244-919-A CD-672 BOARD, COMPLETE
(DVD710E/DVD810E)
A-1244-919-A CD-687 BOARD, COMPLETE
(DVD310E/DVD410E/DVD710/DVD710E/
DVD810/DVD810E) (Note 1)
**********************
(IC7002 (CCD imager) is not included in
CD-672/CD-687 complete board.
Included in CCD block assy.)
< CAPACITOR >
C7002 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C7003 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C7005 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7006 1-100-591-91 CERAMIC CHIP 1uF 10% 25V
(CD-672)
C7007 1-127-820-11 CERAMIC CHIP 4.7uF 10% 16V
C7010 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
(CD-672)
C7011 1-165-875-11 CERAMIC CHIP 10uF 10% 10V
C7015 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7016 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7017 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7018 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C7023 1-127-760-11 CERAMIC CHIP 4.7uF 10% 6.3V
C7024 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C7025 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C7026 1-100-251-11 CERAMIC CHIP 0.047uF 10% 10V
C7027 1-100-251-11 CERAMIC CHIP 0.047uF 10% 10V
C7028 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C7029 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
< CONNECTOR >
CN7001 1-820-586-51 CONNECTOR, FFC/FPC 28P
< FERRITE BEAD >
FB7001 1-400-331-11 FERRITE, EMI (SMD) (1005)
< IC >
IC7002 (Not supplied) ICX617AKF-H (CCD IMAGER) (Note 2)
(IC7002 is supplied including in CCD block assy.)
IC7003 8-759-489-19 IC uPC6756GR-8JG-E2
< COIL >
L7001 1-400-588-11 INDUCTOR 10uH
L7002 1-400-588-11 INDUCTOR 10uH
< TRANSISTOR >
Q7001 6-550-234-01 TRANSISTOR UNR32A300LS0
Q7002 8-729-055-21 TRANSISTOR 2SC5096-O/R (TE85L)
< RESISTOR >
R7002 1-218-954-11 RES-CHIP 1.2K 5% 1/16W
R7004 1-218-965-11 RES-CHIP 10K 5% 1/16W
R7005 1-218-953-11 RES-CHIP 1K 5% 1/16W
R7006 1-218-966-11 RES-CHIP 12K 5% 1/16W
R7013 1-218-965-11 RES-CHIP 10K 5% 1/16W
R7014 1-218-989-11 RES-CHIP 1M 5% 1/16W
R7015 1-218-989-11 RES-CHIP 1M 5% 1/16W
R7016 1-218-965-11 RES-CHIP 10K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
* RB7001 1-234-379-21 RES, NETWORK 22K (1005X4)
< ANGULAR VELOCITY SENSOR >
* SE7001 1-479-022-61 SENSOR, ANGULAR VELOCITY (YAW)
* SE7002 1-479-022-51 SENSOR, ANGULAR VELOCITY (PITCH)
BL-021 BL-022 CD-672 CD-687
Note 2: イメージャの交換時は4-3ページのイメージャ
交換時の注意を必ずお読みください。
Note 1: CD-687基板は供給されません。代わりにCD-672
基板が供給されます。
Note 2: Be sure to read “Precautions for Replacement of
Imager” on page 4-2 when changing the imager.
Note 1: CD-672 complete board is supplied instead of
CD-687 complete board, because CD-672
complete board and CD-687 complete board are
compatible.
