5-13
Ref. No. Part No. Description Ref. No. Part No. Description
DCR-DVD110E/DVD115E/DVD310E/DVD410E/DVD610/
DVD610E/DVD710/DVD710E/DVD810/DVD810E_L2
A-1228-528-A FP-569 FLEXIBLE BOARD, COMPLETE
*******************************
< DIODE >
D5691 6-500-817-01 DIODE SML-512UWT86 (ACCESS)
< SWITCH >
S5691 1-786-148-11 SWITCH, PUSH (1 KEY) (OPEN)
S5692 1-786-148-11 SWITCH, PUSH (1 KEY) (LID OPEN DETECT)
S5693 1-786-148-11 SWITCH, PUSH (1 KEY) (LID OPEN DETECT)
S5694 1-786-179-31 SWITCH, PUSH (1 KEY) (EJECT DETECT)
1-874-948-11 FP-839 FLEXIBLE BOARD
********************
(BH001 and J001 are not included in
FP-839 flexible board.)
< BATTERY TERMINAL >
0BH001 1-780-064-21 BATTERY TERMINAL BOARD
< CONNECTOR >
0J001 1-815-792-11 CONNECTOR, DC-IN (7.2V) (DC IN)
A-1439-631-A MS-391 BOARD, COMPLETE
(DVD110E/DVD115E/DVD610/DVD610E)
***********************
< CONNECTOR >
* CN7301 1-816-646-51 FFC/CONNECTOR, FPC (LIF) 16P
CN7302 1-819-613-22 MEMORY STICK DUO CONNECTOR 10P
< FERRITE BEAD >
FB7301 1-469-580-21 INDUCTOR, FERRITE BEAD (1005)
FB7302 1-469-580-21 INDUCTOR, FERRITE BEAD (1005)
FB7303 1-469-580-21 INDUCTOR, FERRITE BEAD (1005)
FB7304 1-469-580-21 INDUCTOR, FERRITE BEAD (1005)
< RESISTOR >
R7302 1-218-942-11 RES-CHIP 120 5% 1/16W
R7303 1-218-942-11 RES-CHIP 120 5% 1/16W
R7306 1-218-942-11 RES-CHIP 120 5% 1/16W
R7307 1-218-942-11 RES-CHIP 120 5% 1/16W
< SWITCH >
* S7301 1-786-545-41 SWITCH, PUSH LEVER (S)
(PANEL OPEN/CLOSE)
A-1439-645-A MS-392 BOARD, COMPLETE
(DVD310E/DVD410E/DVD710/DVD710E/
DVD810/DVD810E)
**********************
< CONNECTOR >
* CN7301 1-816-646-51 FFC/CONNECTOR, FPC (LIF) 16P
CN7302 1-819-613-22 MEMORY STICK DUO CONNECTOR 10P
< FERRITE BEAD >
FB7301 1-469-580-21 INDUCTOR, FERRITE BEAD (1005)
FB7302 1-469-580-21 INDUCTOR, FERRITE BEAD (1005)
FB7303 1-469-580-21 INDUCTOR, FERRITE BEAD (1005)
FB7304 1-469-580-21 INDUCTOR, FERRITE BEAD (1005)
< IC >
* IC7301 6-600-563-01 IC RS-450-T
< RESISTOR >
R7302 1-218-942-11 RES-CHIP 120 5% 1/16W
R7303 1-218-942-11 RES-CHIP 120 5% 1/16W
R7306 1-218-942-11 RES-CHIP 120 5% 1/16W
R7307 1-218-942-11 RES-CHIP 120 5% 1/16W
< SWITCH >
* S7301 1-786-545-41 SWITCH, PUSH LEVER (S)
(PANEL OPEN/CLOSE)
A-1439-627-A PD-351 BOARD, COMPLETE
(DVD110E/DVD115E/DVD610/DVD610E)
**********************
< CAPACITOR >
C6202 1-100-581-81 CERAMIC CHIP 0.0047uF 10% 50V
C6203 1-100-581-81 CERAMIC CHIP 0.0047uF 10% 50V
C6205 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6206 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
< CONNECTOR >
* CN6201 1-818-072-61 CONNECTOR, FFC/FPC (ZIF) 30P
* CN6202 1-818-069-61 CONNECTOR, FFC/FPC (ZIF) 6P
* CN6204 1-818-069-61 CONNECTOR, FFC/FPC (ZIF) 6P
CN6205 1-815-031-51 FFC/CONNECTOR, FPC (ZIF) 24P
< DIODE >
D6202 8-719-074-67 DIODE EDZ-TE61-5.6B
* D6203 6-501-476-01 DIODE NSSW008CT-T071 (BACKLIGHT)
* D6204 6-501-476-01 DIODE NSSW008CT-T071 (BACKLIGHT)
* D6205 6-501-476-01 DIODE NSSW008CT-T071 (BACKLIGHT)
< TRANSISTOR >
Q6201 8-729-427-67 TRANSISTOR XP421F-TXE
Q6202 8-729-427-37 TRANSISTOR XP411F-TXE
< RESISTOR >
R6201 1-218-954-11 RES-CHIP 1.2K 5% 1/16W
R6202 1-218-955-11 RES-CHIP 1.5K 5% 1/16W
R6203 1-218-957-11 RES-CHIP 2.2K 5% 1/16W
R6209 1-218-989-11 RES-CHIP 1M 5% 1/16W
• Refer to page 5-1 for mark 0.
FP-569 FP-839 MS-391 MS-392 PD-351
