– 30 –
• IC301 ZR38600PQC-RCB7A (AC-3/PROLOGIC SURROUND DECODER)
Pin No. Pin Name I/O Pin Description
1 A0 — Not used. (open)
2 GND — Ground
3 SS I Host serial interface slave select signal input
4 TMS — Not used. (Connect to ground.)
5 INT I External interference request signal input
6V
DD
— Power supply pin (+3.3 V)
7 R14/RDY — Not used. (open)
8 GND — Ground
9 – 11 A1 – 3 — Not used. (open)
12 V
DD
— Power supply pin (+3.3 V)
13 D13/C/B — Not used. (open)
14 GPIO5 — Not used. (open)
15 D12/ERR — Not used. (open)
16 A4 — Not used. (open)
17 V
DD
— Power supply pin (+3.3 V)
18 GPIO4 — Not used. (open)
19 GND — Ground
20, 21 A5, A6 — Not used. (open)
22 D11/PP7 — Not used. (open)
23 GPIO3 — Not used. (open)
24, 25 A7, A8 — Not used. (open)
26 D10/PP6 — Not used. (open)
27, 28 A9, A10 — Not used. (open)
29 GND — Ground
30 V
DD
— Power supply pin (+3.3 V)
31 A11 — Not used. (open)
32 D9/PP5 — Not used. (open)
33 D8/PP4 — Not used. (open)
34 SO O Host serial interface data signal output
35 V
DD
— Power supply pin (+3.3 V)
36 SELECT — Not used. (open)
37 GND — Ground
38 A12 — Not used. (open)
39 TBO — Not used. (open)
40 A13 — Not used. (open)
41 D7/PP3 — Not used. (open)
42 D6/PP2 — Not used. (open)
43 A14 — Not used. (open)
44 GND — Ground
45 V
DD
— Power supply pin (+3.3 V)
46 A15 — Not used. (open)
47 D5/PP1 — Not used. (open)
48 D4/PP0 I/O
Resemblance port data bus signal of external memory select and resemblance port
input/output.
49 A16 — Not used. (open)
50 RD I/O External memory read possible signal input/output
51 WR I/O External memory wright possible signal input/output
52 CS I/O External memory chip select signal input/output
53 GND — Ground
54 SDD — Not used. (open)
55 V
DD
— Power supply pin (+3.3 V)
56 GPIO2 — Not used. (open)
