23
DXA-WZ8D
R539 1-216-839-11 METAL CHIP 33K 5% 1/10W
R540 1-216-845-11 METAL CHIP 100K 5% 1/10W
R541 1-216-841-11 METAL CHIP 47K 5% 1/10W
R542 1-216-845-11 METAL CHIP 100K 5% 1/10W
R543 1-216-843-11 METAL CHIP 68K 5% 1/10W
R544 1-216-845-11 METAL CHIP 100K 5% 1/10W
R545 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R546 1-216-841-11 METAL CHIP 47K 5% 1/10W
R547 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R548 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R551 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R552 1-216-845-11 METAL CHIP 100K 5% 1/10W
R553 1-216-833-11 METAL CHIP 10K 5% 1/10W
R554 1-216-821-11 METAL CHIP 1K 5% 1/10W
R555 1-216-841-11 METAL CHIP 47K 5% 1/10W
R556 1-202-922-91 METAL CHIP 110 5% 1/10W
(AEP, UK, RU)
R556 1-216-810-91 METAL FILM 120 5% 1/10W
(EXCEPT AEP, UK, RU)
R557 1-216-833-11 METAL CHIP 10K 5% 1/10W
R571 1-216-821-11 METAL CHIP 1K 5% 1/10W
R572 1-220-894-11 METAL 0.22 10% 5W
R573 1-216-841-11 METAL CHIP 47K 5% 1/10W
R574 1-249-625-31 CARBON 10 5% 1/2W
R575 1-216-847-11 METAL CHIP 150K 5% 1/10W
R576 1-216-835-11 METAL CHIP 15K 5% 1/10W
< THERMISTOR >
TH531 1-807-796-11 THERMISTOR
************************************************************
A-4732-226-A SURROUND AMP BOARD, COMPLETE
(AEP, UK, RU)
******************************
A-4732-236-A SURROUND AMP BOARD, COMPLETE
(E2, E3, E15, EA, MY, SP, PH)
******************************
A-4732-266-A SURROUND AMP BOARD, COMPLETE (AUS)
******************************
A-4734-576-A SURROUND AMP BOARD, COMPLETE (KR)
******************************
A-4734-591-A SURROUND AMP BOARD, COMPLETE (TH)
******************************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S (EXCEPT TH)
< CAPACITOR >
C701 1-126-964-11 ELECT 10uF 20.00% 50V
C702 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C703 1-126-967-11 ELECT 47uF 20.00% 50V
C704 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C708 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C709 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C712 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C713 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C731 1-126-964-11 ELECT 10uF 20.00% 50V
C732 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C733 1-126-967-11 ELECT 47uF 20.00% 50V
C734 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C742 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C743 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C751 1-126-964-11 ELECT 10uF 20.00% 50V
C752 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C753 1-126-967-11 ELECT 47uF 20.00% 50V
C754 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C762 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C763 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C771 1-126-965-91 ELECT 22uF 20.00% 50V
< CONNECTOR >
CN605 1-568-106-11 PIN, CONNECTOR (3.96mm PITCH) 4P
(EXCEPT AEP, UK, RU)
CN701 1-785-332-11 PIN, CONNECTOR (LIGHT ANGLE) 6P
< DIODE >
D711 8-719-988-61 DIODE 1SS355TE-17
D741 8-719-988-61 DIODE 1SS355TE-17
D742 8-719-988-61 DIODE 1SS355TE-17
D761 8-719-988-61 DIODE 1SS355TE-17
< TERMINAL >
* EP701 1-537-738-21 TERMINAL, EARTH
< IC >
IC701 6-600-173-01 IC STK403-240
< TRANSISTOR >
Q701 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q711 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q731 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q741 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q751 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q761 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
< RESISTOR >
R700 1-216-833-11 METAL CHIP 10K 5% 1/10W
R701 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R702 1-216-845-11 METAL CHIP 100K 5% 1/10W
R703 1-216-821-11 METAL CHIP 1K 5% 1/10W
R704 1-216-821-11 METAL CHIP 1K 5% 1/10W
R705 1-216-841-11 METAL CHIP 47K 5% 1/10W
R706 1-216-819-11 METAL CHIP 680 5% 1/10W
R711 1-216-841-11 METAL CHIP 47K 5% 1/10W
R712 1-216-835-11 METAL CHIP 15K 5% 1/10W
R713 1-216-821-11 METAL CHIP 1K 5% 1/10W
R714 1-220-755-11 METAL 0.22 10% 2W
R715 1-216-845-11 METAL CHIP 100K 5% 1/10W
R716 1-260-304-51 CARBON 10 5% 1/2W
R731 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R732 1-216-845-11 METAL CHIP 100K 5% 1/10W
R733 1-216-821-11 METAL CHIP 1K 5% 1/10W
R734 1-216-821-11 METAL CHIP 1K 5% 1/10W
R735 1-216-841-11 METAL CHIP 47K 5% 1/10W
R736 1-216-819-11 METAL CHIP 680 5% 1/10W
R741 1-216-841-11 METAL CHIP 47K 5% 1/10W
R742 1-216-835-11 METAL CHIP 15K 5% 1/10W
R743 1-216-821-11 METAL CHIP 1K 5% 1/10W
Ref. No. Part No. Description RemarksRef. No. Part No. Description Remarks
FRONT AMP SURROUND AMP
