7
DXA-WZ8D
2
two screws
(+BVTP 3
×
8)
5
two screws
(+BVTP 3
×
8)
1
Remove the soldering.
4
Remove the soldering.
3
FRONT
AMP board
6
SURROUND
AMP board
7
front panel assy
1
two screws
(+BVTP 3
×
8)
4
claw
2
wire (flat type)
(13 core)
3
lead with connector
5
connector
6
connector
2-4. FRONT AMP Board and SURROUND AMP Board
2-5. Front Panel Assy
