8
DXA-WZ8D
1
four screws
(+BVTP 2.6
×
8
)
4
two screws
(+BVTP 2.6
×
8)
3
2
tape
mechanism deck (CWM43RR23)
5
four claws
6
base lock
q;
holder (lock)
7
lever (R)
9
lever (C)
8
lever (L)
qa
button (A)
qs
button (B)
1
spring (lid)
2
spring (lid-R)
3
lid (TC) assy
4
claw
8
claw
5
damper
9
damper
6
spring holder (A)
q;
spring holder (B)
7
holder (A) assy
qa
holder (B) assy
2-6. Tape Mechanism Deck (CWM43RR23)
2-7. Lid (TC) Assy, Holder (A) Assy and Holder (B) Assy
