22
DXA-WZ8D
SECTION 6
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
•-XX, -X mean standardized parts, so they may
have some difference from the original one.
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
• CAPACITORS:
uF: µF
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
•Abbreviation
AUS: Australian model
E2 : 120V AC area in E model
E3 : 240V AC area in E model
E15 : 220-240V AC area in E model
EA : Saudi Arabia model
KR : Korean model
MY : Malaysia model
PH : Philippines model
RU : Russian model
SP : Singapore model
TH : Thai model
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
A-4732-224-A FRONT AMP BOARD, COMPLETE (AEP, UK, RU)
**************************
A-4732-234-A FRONT AMP BOARD, COMPLETE
(E2, E3, E15, EA, MY, SP, PH)
**************************
A-4732-264-A FRONT AMP BOARD, COMPLETE (AUS)
**************************
A-4734-574-A FRONT AMP BOARD, COMPLETE (KR)
**************************
A-4734-588-A FRONT AMP BOARD, COMPLETE (TH)
**************************
< CAPACITOR >
C501 1-126-964-11 ELECT 10uF 20.00% 50V
C502 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C503 1-126-947-11 ELECT 47uF 20.00% 16V
C504 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C505 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C508 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C521 1-131-992-91 CERAMIC CHIP 100000PF 35V
C522 1-131-992-91 CERAMIC CHIP 100000PF 35V
C531 1-128-560-11 ELECT 22uF 20.00% 100V
C532 1-128-560-11 ELECT 22uF 20.00% 100V
C533 1-126-967-11 ELECT 47uF 20.00% 50V
C534 1-128-562-11 ELECT 47uF 20.00% 100V
C551 1-126-964-11 ELECT 10uF 20.00% 50V
C552 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C553 1-126-947-11 ELECT 47uF 20.00% 16V
C554 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
C571 1-131-992-91 CERAMIC CHIP 100000PF 35V
C572 1-131-992-91 CERAMIC CHIP 100000PF 35V
< CONNECTOR >
* CN501 1-506-486-11 PIN, CONNECTOR 7P
* CN502 1-564-523-11 PLUG, CONNECTOR 8P
< DIODE >
D501 8-719-988-61 DIODE 1SS355TE-17
D504 8-719-083-63 DIODE UDZSTE-1713B
D505 8-719-083-63 DIODE UDZSTE-1713B
D521 8-719-988-61 DIODE 1SS355TE-17
D532 8-719-988-61 DIODE 1SS355TE-17
D571 8-719-988-61 DIODE 1SS355TE-17
< IC >
IC501 6-600-179-01 IC STK412-210 (AEP, UK, RU)
IC501 6-600-171-01 IC STK412-230 (EXCEPT AEP, UK, RU)
< JUMPER RESISTOR >
JR501 1-216-864-11 METAL CHIP 0 5% 1/10W
JR502 1-216-864-11 METAL CHIP 0 5% 1/10W
(TH)
< TRANSISTOR >
Q501 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q521 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
Q533 8-729-271-31 TRANSISTOR 2SC2713G-TE85L
Q534 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
Q535 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
Q536 8-729-216-31 TRANSISTOR 2SA1163G-TE85L
Q537 8-729-120-28 TRANSISTOR 2SC1623-T1-L5L6
Q551 8-729-141-73 TRANSISTOR 2SC3624A-T1L15L16
Q571 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA
< RESISTOR >
R500 1-216-833-11 METAL CHIP 10K 5% 1/10W
R501 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R502 1-216-845-11 METAL CHIP 100K 5% 1/10W
R503 1-216-833-11 METAL CHIP 10K 5% 1/10W
R504 1-216-821-11 METAL CHIP 1K 5% 1/10W
R505 1-216-841-11 METAL CHIP 47K 5% 1/10W
R506 1-202-922-91 METAL CHIP 110 5% 1/10W
(AEP, UK, RU)
R506 1-216-810-91 METAL FILM 120 5% 1/10W
(EXCEPT AEP, UK, RU)
R507 1-216-833-11 METAL CHIP 10K 5% 1/10W
R510 1-216-839-11 METAL CHIP 33K 5% 1/10W
R521 1-216-821-11 METAL CHIP 1K 5% 1/10W
R522 1-220-894-11 METAL 0.22 10% 5W
R523 1-216-841-11 METAL CHIP 47K 5% 1/10W
R524 1-249-625-31 CARBON 10 5% 1/2W
R525 1-216-847-11 METAL CHIP 150K 5% 1/10W
R526 1-216-835-11 METAL CHIP 15K 5% 1/10W
R530 1-216-809-11 METAL CHIP 100 5% 1/10W
0R531 1-217-637-00 FUSIBLE 1 5% 1/4W
R534 1-216-837-11 METAL CHIP 22K 5% 1/10W
0R535 1-212-881-11 FUSIBLE 100 5% 1/4W
0R537 1-212-881-11 FUSIBLE 100 5% 1/4W
FRONT AMP
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
