27
DXA-WZ8D
R402 1-216-841-11 METAL CHIP 47K 5% 1/10W
R403 1-216-841-11 METAL CHIP 47K 5% 1/10W
R404 1-216-843-11 METAL CHIP 68K 5% 1/10W
R405 1-216-841-11 METAL CHIP 47K 5% 1/10W
0R406 1-215-859-51 METAL OXIDE 22 5% 1W
(AEP, UK, RU)
0R406 1-216-360-51 METAL OXIDE 82 5% 1W
R408 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R409 1-216-833-11 METAL CHIP 10K 5% 1/10W
R410 1-216-845-11 METAL CHIP 100K 5% 1/10W
0R411 1-215-859-51 METAL OXIDE 22 5% 1W
(AEP, UK, RU)
0R411 1-216-360-51 METAL OXIDE 82 5% 1W
(EXCEPT AEP, UK, RU)
0R412 1-215-859-51 METAL OXIDE 22 5% 1W
(AEP, UK, RU)
0R412 1-216-360-51 METAL OXIDE 82 5% 1W
(EXCEPT AEP, UK, RU)
R413 1-216-837-11 METAL CHIP 22K 5% 1/10W
R414 1-216-821-11 METAL CHIP 1K 5% 1/10W
R415 1-216-837-11 METAL CHIP 22K 5% 1/10W
R417 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R419 1-216-833-11 METAL CHIP 10K 5% 1/10W
R420 1-216-841-11 METAL CHIP 47K 5% 1/10W
R421 1-216-841-11 METAL CHIP 47K 5% 1/10W
R422 1-216-841-11 METAL CHIP 47K 5% 1/10W
R423 1-216-841-11 METAL CHIP 47K 5% 1/10W
R424 1-260-304-51 CARBON 10 5% 1/2W
(AEP, UK, RU, KR)
R425 1-216-841-11 METAL CHIP 47K 5% 1/10W
R426 1-260-304-51 CARBON 10 5% 1/2W
(AEP, UK, RU, KR)
R427 1-260-304-51 CARBON 10 5% 1/2W
(AEP, UK, RU, KR)
R428 1-260-304-51 CARBON 10 5% 1/2W
(AEP, UK, RU, KR)
R429 1-260-304-51 CARBON 10 5% 1/2W
(AEP, UK, RU, KR)
R430 1-260-304-51 CARBON 10 5% 1/2W
(AEP, UK, RU, KR)
R431 1-260-304-51 CARBON 10 5% 1/2W
(AEP, UK, RU, KR)
R432 1-260-304-51 CARBON 10 5% 1/2W
(AEP, UK, RU, KR)
R433 1-260-304-51 CARBON 10 5% 1/2W
(AEP, UK, RU, KR)
R434 1-260-304-51 CARBON 10 5% 1/2W
(AEP, UK, RU, KR)
R601 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
< RELAY >
RY401 1-755-416-12 RELAY
RY402 1-755-372-11 RELAY
RY403 1-755-416-12 RELAY
0RY601 1-755-332-11 RELAY
< SWITCH >
0S601 1-771-291-31 SWITCH, POWER (VOLTAGE SELECTOR)
(E2, E3, E15, EA, MY, SP, PH)
< TRANSFORMER >
T301 1-433-372-11 TRANSFORMER, BIAS OSCILLATION
< TERMINAL >
TM401 1-694-656-21 TERMINAL BOARD (6CH SPEAKER)
************************************************************
MISCELLANEOUS
**************
055 1-468-737-11 POWER, SWITCHING
056 1-769-079-12 CORD, POWER (KR)
056 1-775-786-41 CORD, POWER (UK)
056 1-775-790-51 CORD, POWER (AUS)
056 1-777-071-63 CORD, POWER (AEP, RU, EA, MY, SP, PH)
056 1-824-818-11 CORD, POWER (WITH CONNECTOR)(TH)
056 1-827-226-21 CORD, POWER (E2, E3, E15)
59 1-500-386-11 FILTER, CLAMP (FERRITE CORE)
101 1-796-487-31 DECK, MECHANICAL
0F101 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) T6.3AL/250V
0F102 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) T6.3AL/250V
0F103 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) T6.3AL/250V
0F104 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) T6.3AL/250V
0F105 1-533-471-11 FUSE, GLASS TUBE (DIA. 4) T5AL/250V
0F106 1-533-472-11 FUSE, GLASS TUBE (DIA. 5) T5AL/250V
0F601 1-533-471-11 FUSE, GLASS TUBE (DIA. 5) T4AL/250V
(E2, E3, E15, MY, SP, PH)
0F601 1-533-473-11 FUSE, GLASS TUBE (DIA. 5) T6.3AL/250V (EA)
0T302 1-439-643-11 TRANSFORMER, POWER (EA)
0T302 1-439-644-11 TRANSFORMER, POWER
(E2, E3, E15, MY, SP, KR, TH, PH, AUS)
0T302 1-439-645-11 TRANSFORMER, POWER (AEP, UK, RU)
0FAN301 1-763-488-31 FAN, DC
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
