Sony HCD-101 - Chassis Section

— 48 —
51 1-668-138-11 POSISTOR BOARD
* 52 1-667-384-11 TRANS BOARD
* 53 4-995-817-01 COVER (CABLE)
54 1-782-780-11 WIRE (FLAT TYPE) (21 CORE)
* 55 1-667-823-11 POWER IC BOARD
* 56 A-4403-527-A PRE BOARD, COMPLETE
* 57 4-994-816-01 PANEL, BACK
58 1-698-997-11 FAN, DC
* 59 A-4403-536-A FUNCTION BOARD, COMPLETE (SP,MY,HK,JE)
* 59 A-4403-553-A FUNCTION BOARD, COMPLETE (AEP,G)
* 59 A-4403-726-A FUNCTION BOARD, COMPLETE (UK)
60 4-965-822-01 FOOT
* 61 A-4403-537-A POWER BOARD, COMPLETE (SP,MY,HK,JE)
* 61 A-4403-555-A POWER BOARD, COMPLETE (AEP,G,UK)
* 62 1-667-822-11 RELAY BOARD
* 63 1-667-386-11 SP TM BOARD
64 4-985-672-01 SCREW (+PTPWHM2.6), FLOATING
! 65 1-776-060-11 CORD, POWER (EXCEPT UK)
! 65 1-776-061-21 CORD, POWER (UK)
66 3-703-244-00 BUSHING (2104), CORD
* 67 4-994-825-01 COVER (TR)
68 4-812-134-11 RIVET (DIA. 3.5), NYLON
69 4-889-836-01 CUSHION
* 70 1-667-382-11 VOLSEL BOARD
* 71 A-4403-559-A RDS BOARD, COMPLETE (AEP,G,UK)
! 72 1-569-008-11 ADAPTOR, CONVERSION 2P (SP,MY)
! 73 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (HK)
! T901 1-431-559-11 TRANSFORMER, POWER (AEP,G,UK)
! T901 1-431-560-11 TRANSFORMER, POWER (SP,MY,HK,JE)
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
6-2. CHASSIS SECTION
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
#1
#1
#5
#1
#1
#1
56
53
#1
#1
#5
#1
#1
61
54
55
#5
#4
68
58
#2
#3
T901
#3
64
#5
#3
#5
#5
#5
#3
66
70
71
52
not supplied
not supplied
not supplied
69
51
59
SP, MY
MODEL
HK
MODEL
UK
MODEL
EXCEPT UK
MODEL
73
73
65
65
72
60
not supplied
57
65
63
67
62
