NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 51 —
SECTION 7
ELECTRICAL PARTS LIST
• Abbreviation
SP : Singapore
MY : Malaysia
HK : Hong Kong
G : German
JE : Tourist
* A-4699-821-A BD BOARD, COMPLETE
*******************
3-934-077-01 CUSHION (LIGHT INTERCEPTION)
< CAPACITOR >
C101 1-126-607-11 ELECT CHIP 47uF 20% 4V
C102 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C103 1-164-346-11 CERAMIC CHIP 1uF 16V
C105 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C106 1-164-695-11 CERAMIC CHIP 0.0022uF 5% 50V
C107 1-164-695-11 CERAMIC CHIP 0.0022uF 5% 50V
C108 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C109 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C110 1-163-989-11 CERAMIC CHIP 0.033uF 10% 25V
C111 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C112 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C113 1-164-695-11 CERAMIC CHIP 0.0022uF 5% 50V
C114 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C115 1-126-607-11 ELECT CHIP 47uF 20% 4V
C116 1-163-016-00 CERAMIC CHIP 0.0039uF 10% 50V
C117 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C118 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C119 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C120 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C121 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C122 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C123 1-164-336-11 CERAMIC CHIP 0.33uF 25V
C124 1-126-607-11 ELECT CHIP 47uF 20% 4V
C125 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C126 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C127 1-164-695-11 CERAMIC CHIP 0.0022uF 5% 50V
C128 1-163-135-00 CERAMIC CHIP 560PF 5% 50V
C129 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C130 1-164-336-11 CERAMIC CHIP 0.33uF 25V
C131 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C132 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C133 1-163-145-00 CERAMIC CHIP 0.0015uF 5% 50V
C134 1-164-346-11 CERAMIC CHIP 1uF 16V
C135 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C136 1-164-005-11 CERAMIC CHIP 0.47uF 25V
C137 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C139 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C140 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C141 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C142 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C145 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C146 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C147 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C148 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C149 1-164-346-11 CERAMIC CHIP 1uF 16V
C153 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C154 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C171 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C172 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C173 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C174 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C175 1-124-778-00 ELECT CHIP 22uF 20% 6.3V
C178 1-164-232-11 CERAMIC CHIP 0.01uF 50V
C179 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C180 1-128-065-11 ELECT 68uF 20% 10V
C181 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C182 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C183 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C184 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
CN101 1-565-728-11 CONNECTOR, FPC 17P
CN102 1-770-298-31 HOUSING, CONNECTOR 28P
CN104 1-580-055-21 PIN, CONNECTOR 2P
CN105 1-774-417-11 CONNECTOR, FPC 5P
CN106 1-770-345-21 CONNECTOR, FPC 7P
CN107 1-778-638-21 PIN, CONNECTOR (PC BOARD) 2P
< FERRITE BEAD >
FB101 1-500-245-11 INDUCTOR 0UH
FB102 1-216-295-91 CONDUCTOR, CHIP (2012)
FB103 1-500-245-11 INDUCTOR 0UH
FB104 1-216-295-91 CONDUCTOR, CHIP (2012)
FB105 1-414-386-11 INDUCTOR, FERRITE BEAD
FB106 1-414-386-11 INDUCTOR, FERRITE BEAD
< IC >
IC101 8-752-069-56 IC CXA1782BQ
IC102 8-759-291-06 IC BA6397FP
IC103 8-752-372-94 IC CXD2507AQ
IC104 8-759-185-29 IC PCM1710U-B
IC105 8-759-823-87 IC LB1638M
BD
To Next Page
