Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 52 —
< TRANSISTOR >
Q1 8-729-032-35 PHOTO TRANSISTOR CPT-230S-C-TU
Q2 8-729-032-35 PHOTO TRANSISTOR CPT-230S-C-TU
Q4 8-729-032-35 PHOTO TRANSISTOR CPT-230S-C-TU
Q101 8-729-010-08 TRANSISTOR MSB710-R
Q102 8-729-424-08 TRANSISTOR UN2111
< RESISTOR >
R102 1-216-001-00 METAL CHIP 10 5% 1/10W
R103 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R104 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R105 1-216-093-00 METAL CHIP 68K 5% 1/10W
R106 1-216-093-00 METAL CHIP 68K 5% 1/10W
R107 1-216-093-00 METAL CHIP 68K 5% 1/10W
R108 1-216-093-00 METAL CHIP 68K 5% 1/10W
R109 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R112 1-216-083-00 METAL CHIP 27K 5% 1/10W
R113 1-216-083-00 METAL CHIP 27K 5% 1/10W
R114 1-216-101-00 METAL CHIP 150K 5% 1/10W
R115 1-216-101-00 METAL CHIP 150K 5% 1/10W
R116 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R117 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R118 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R119 1-216-089-91 METAL GLAZE 47K 5% 1/10W
R120 1-216-089-91 METAL GLAZE 47K 5% 1/10W
R121 1-216-114-00 METAL GLAZE 510K 5% 1/10W
R122 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R123 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R124 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R125 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R126 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R127 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R128 1-216-105-91 METAL GLAZE 220K 5% 1/10W
R129 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R130 1-216-079-00 METAL CHIP 18K 5% 1/10W
R131 1-216-079-00 METAL CHIP 18K 5% 1/10W
R132 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R133 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R134 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R135 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R136 1-216-073-00 METAL CHIP 10K 5% 1/10W
R137 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R138 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R139 1-216-033-00 METAL CHIP 220 5% 1/10W
R140 1-216-081-00 METAL CHIP 22K 5% 1/10W
R141 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R142 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R143 1-216-121-91 METAL GLAZE 1M 5% 1/10W
R144 1-216-073-00 METAL CHIP 10K 5% 1/10W
R145 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R146 1-216-097-91 METAL GLAZE 100K 5% 1/10W
R147 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R148 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R149 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R150 1-216-037-00 METAL CHIP 330 5% 1/10W
R151 1-216-037-00 METAL CHIP 330 5% 1/10W
R152 1-216-037-00 METAL CHIP 330 5% 1/10W
R154 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R156 1-216-085-00 METAL CHIP 33K 5% 1/10W
R157 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R158 1-216-001-00 METAL CHIP 10 5% 1/10W
R171 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R172 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R173 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R174 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R175 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R176 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R177 1-216-049-91 METAL GLAZE 1K 5% 1/10W
R183 1-216-105-91 METAL GLAZE 220K 5% 1/10W
R184 1-216-105-91 METAL GLAZE 220K 5% 1/10W
R185 1-216-105-91 METAL GLAZE 220K 5% 1/10W
R186 1-216-295-91 CONDUCTOR, CHIP (2012)
R187 1-216-295-91 CONDUCTOR, CHIP (2012)
R188 1-216-295-91 CONDUCTOR, CHIP (2012)
R189 1-216-295-91 CONDUCTOR, CHIP (2012)
< VARIABLE RESISTOR >
RV101 1-223-587-11 RES, ADJ, CARBON 22K
RV102 1-223-587-11 RES, ADJ, CARBON 22K
RV103 1-223-587-11 RES, ADJ, CARBON 22K
< SWITCH >
S1 1-571-754-31 SWITCH, PUSH (1 KEY)
< VIBRATOR >
X101 1-767-430-11 VIBRATOR, CRYSTAL 16.9344MHz
************************************************************
* 1-667-388-11 EJECT BOARD
***********
< CONNECTOR >
CN753 1-580-918-11 HOUSING, CONNECTOR 5P
< SWITCH >
S755 1-762-875-21 SWITCH, KEYBOARD (6OPEN/CLOSE)
************************************************************
* A-4403-553-A FUNCTION BOARD, COMPLETE (AEP,G)
*************************
A-4403-536-A FUNCTION BOARD, COMPLETE (SP,MY,HK,JE)
*************************
* A-4403-726-A FUNCTION BOARD, COMPLETE (UK)
*************************
< CAPACITOR >
C401 1-162-282-31 CERAMIC 100PF 10% 50V
(AEP,G,UK)
C402 1-126-791-11 ELECT 10uF 20% 35V
C403 1-162-282-31 CERAMIC 100PF 10% 50V
(AEP,G,UK)
C404 1-162-282-31 CERAMIC 100PF 10% 50V
(AEP,G,UK)
C405 1-162-282-31 CERAMIC 100PF 10% 50V
(AEP,G,UK)
C406 1-126-791-11 ELECT 10uF 20% 35V
BD EJECT FUNCTION
