Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 53 —
C407 1-162-282-31 CERAMIC 100PF 10% 50V
(AEP,G,UK)
C408 1-162-282-31 CERAMIC 100PF 10% 50V
(AEP,G,UK)
C426 1-164-159-11 CERAMIC 0.1uF 50V
C430 1-164-159-11 CERAMIC 0.1uF 50V
C431 1-164-159-11 CERAMIC 0.1uF 50V
C432 1-126-059-11 ELECT 10uF 20% 50V
C433 1-126-059-11 ELECT 10uF 20% 50V
C436 1-164-159-11 CERAMIC 0.1uF 50V
C437 1-126-934-11 ELECT 220uF 20% 16V
C438 1-164-159-11 CERAMIC 0.1uF 50V
C450 1-164-159-11 CERAMIC 0.1uF 50V
C451 1-161-494-00 CERAMIC 0.022uF 25V
C493 1-164-159-11 CERAMIC 0.1uF 50V
C501 1-162-282-31 CERAMIC 100PF 10% 50V
(AEP,G,UK)
C502 1-126-791-11 ELECT 10uF 20% 35V
C503 1-162-282-31 CERAMIC 100PF 10% 50V
(AEP,G,UK)
C504 1-162-282-31 CERAMIC 100PF 10% 50V
(AEP,G,UK)
C505 1-162-282-31 CERAMIC 100PF 10% 50V
(AEP,G,UK)
C506 1-126-791-11 ELECT 10uF 20% 35V
C507 1-162-282-31 CERAMIC 100PF 10% 50V
(AEP,G,UK)
C508 1-162-282-31 CERAMIC 100PF 10% 50V
(AEP,G,UK)
< CONNECTOR >
CN401 1-770-406-11 CONNECTOR, BOARD TO BOARD 10P
CN402 1-779-968-11 SOCKET, CONNECTOR
* CN403 1-774-813-11 CONNECTOR, BOARD TO BOARD 7P(AEP,G,UK)
* CN404 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
CN407 1-770-408-11 CONNECTOR, BOARD TO BOARD 14P
CN410 1-778-310-11 PLUG, CONNECTOR 2P
< JACK >
CNJ401 1-770-501-11 JACK 10P (MD)
CNJ402 1-770-501-11 JACK 10P (TAPE)
< DIODE >
D401 8-719-911-19 DIODE 1SS119
D402 8-719-911-19 DIODE 1SS119
D403 8-719-911-19 DIODE 1SS119
D404 8-719-933-39 DIODE HZS6C1L
D405 8-719-911-19 DIODE 1SS119
D406 8-719-911-19 DIODE 1SS119 (AEP,G,UK)
D407 8-719-911-19 DIODE 1SS119 (AEP,G,UK)
D408 8-719-911-19 DIODE 1SS119 (AEP,G,UK)
< IC >
IC401 8-759-195-14 IC SC027MG051BCP
IC402 8-759-195-21 IC SC027MG066BF-T1
IC403 8-759-195-21 IC SC027MG066BF-T1
IC501 8-759-195-14 IC SC027MG051BCP
< JACK >
J401 1-573-028-31 JACK, PIN 4P
(VIDEO/PC(L-IN,L-OUT,R-IN,R-OUT))
J402 1-779-940-11 CONNECTOR, COAXIAL
(ANTENNA(AM,FM75 ))
< TRANSISTOR >
Q401 8-729-422-57 TRANSISTOR UN4111
Q404 8-729-620-05 TRANSISTOR 2SC2603-EF
< RESISTOR >
R401 1-249-426-11 CARBON 5.6K 5% 1/4W
R402 1-249-427-11 CARBON 6.8K 5% 1/4W F
R403 1-249-413-11 CARBON 470 5% 1/4W F
R404 1-249-441-11 CARBON 100K 5% 1/4W
R405 1-249-413-11 CARBON 470 5% 1/4W F
R407 1-249-417-11 CARBON 1K 5% 1/4W F
R408 1-249-441-11 CARBON 100K 5% 1/4W
R409 1-249-409-11 CARBON 220 5% 1/4W F
R410 1-249-441-11 CARBON 100K 5% 1/4W
R411 1-249-409-11 CARBON 220 5% 1/4W F
R412 1-249-441-11 CARBON 100K 5% 1/4W
R415 1-249-437-11 CARBON 47K 5% 1/4W
R416 1-249-437-11 CARBON 47K 5% 1/4W
R417 1-249-437-11 CARBON 47K 5% 1/4W
R418 1-249-433-11 CARBON 22K 5% 1/4W
R430 1-247-807-31 CARBON 100 5% 1/4W
R431 1-249-417-11 CARBON 1K 5% 1/4W F
R432 1-249-393-11 CARBON 10 5% 1/4W F
R433 1-249-429-11 CARBON 10K 5% 1/4W
R434 1-260-095-11 CARBON 470 5% 1/2W
R435 1-249-433-11 CARBON 22K 5% 1/4W
R436 1-249-433-11 CARBON 22K 5% 1/4W
R437 1-247-807-31 CARBON 100 5% 1/4W
R438 1-247-807-31 CARBON 100 5% 1/4W
R439 1-247-807-31 CARBON 100 5% 1/4W
R440 1-247-807-31 CARBON 100 5% 1/4W
R441 1-247-807-31 CARBON 100 5% 1/4W
R461 1-247-843-11 CARBON 3.3K 5% 1/4W
R462 1-249-429-11 CARBON 10K 5% 1/4W
R495 1-247-843-11 CARBON 3.3K 5% 1/4W
R501 1-249-426-11 CARBON 5.6K 5% 1/4W
R502 1-249-427-11 CARBON 6.8K 5% 1/4W F
R503 1-249-413-11 CARBON 470 5% 1/4W F
R504 1-249-441-11 CARBON 100K 5% 1/4W
R505 1-249-413-11 CARBON 470 5% 1/4W F
R507 1-249-417-11 CARBON 1K 5% 1/4W F
R508 1-249-441-11 CARBON 100K 5% 1/4W
R509 1-249-409-11 CARBON 220 5% 1/4W F
R510 1-249-441-11 CARBON 100K 5% 1/4W
R511 1-249-409-11 CARBON 220 5% 1/4W F
R512 1-249-441-11 CARBON 100K 5% 1/4W
R561 1-247-843-11 CARBON 3.3K 5% 1/4W
R562 1-249-429-11 CARBON 10K 5% 1/4W
< TUNER UNIT >
TB401 1-233-654-11 ENCAPSULATED COMPONENT (SP,MY,HK,JE)
TB401 1-234-028-11 ENCAPSULATED COMPONENT (UK)
TB401 1-693-377-11 TUNER (AEP,G)
************************************************************
